2006 Lincoln Town Car Info Systems & Data Sheets
The 2006 Lincoln Town Car runs the same 4.6L SOHC 2-valve Romeo V8 as every other 2005–2006 Panther platform vehicle — 224 hp, 272 lb-ft, 9.4:1 compression, mated to the 4R75W 4-speed automatic. Where the Town Car diverges from the Crown Victoria and Grand Marquis at the junction box level is significant: the BJB layout is completely different. There's no Police Interceptor variant to account for, so all the P71-specific police PDB feed positions (111, 113–118) are replaced by luxury-specific circuits — rear power points, rear cigar lighters, rear heated seats, a power deck-lid module feed, moonroof, driver seat module, and trunk pull-down relay. The relay bank also uses micro and mini relay formats rather than the 1/2 ISO and full ISO relays in the Crown Victoria. The CJB reflects the Town Car's more complex body electronics: the Lincoln had standard rear audio/climate controls, an available navigation system, keypad entry, adjustable pedals, and front and rear heated seats — all of which show up as dedicated fuse positions that don't exist on the civilian Crown Vic. If you're working a 2006 Town Car and referencing a Crown Vic diagram, you will get mismatches at multiple positions. The data in this post is Town Car-specific, verified against AllData for the 2006 model year.
Download Your Schematics:
- 2006 Lincoln Town Car Battery Junction Fuse Box Schematic Data Sheet
- 2006 Lincoln Town Car Powertrain Control Module Schematic Data Sheet
- 2006 Lincoln Town Car Central Junction Box Schematic Data Sheet
Resources:
- Ford OBD-2 Diagnostic Trouble Codes List
- 2003–2011 Panther Platform Resources & Manuals List
- Label Installation Guide
Labels:
In this post:
- Engine Specifications
- Transmission Specifications
- Battery Junction Box Fuse Panel Data & Info
- Powertrain Control Module Data & Info
- Central Junction Fuse Box Data & Info
- Known Issues & TSB Reference
- Scheduled Maintenance Intervals
Engine Specifications
The 2006 Town Car uses the same 4.6L Romeo-cast SOHC V8 as the Crown Victoria and Grand Marquis. Output and displacement are identical across all three Panther models for 2006. The Town Car's PCM calibration is specific to the Lincoln — it's not shared with the Crown Vic and it drops several SCP bus indicator lines that were still present on the 2005 unit. If you're sourcing a replacement PCM for a 2006 Town Car, the calibration is model-year and vehicle-line specific, and the module requires VIN programming after installation. All figures below are SAE net.
| Specification | Value |
|---|---|
| Engine Family | Ford Modular V8 — Romeo cast |
| Displacement | 4.6L (4,601 cc / 280.8 cu in) |
| Configuration | V8, 90° — SOHC, 2 valves per cylinder (16 total) |
| Bore × Stroke | 90.2 mm × 90.0 mm (3.55 in × 3.54 in) |
| Compression Ratio | 9.4:1 |
| Horsepower | 224 hp @ 4,800 rpm (SAE net) |
| Torque | 272 lb-ft @ 4,000 rpm (SAE net) |
| Redline | ~5,550 rpm |
| Fuel Type | Unleaded — 87 octane minimum (regular) |
| Fuel Injection | Sequential Multi-Port Fuel Injection (SEFI) |
| Throttle Control | Electronic (Drive-By-Wire / ETC) |
| Ignition | Coil-on-plug (COP) — 8 individual coils, no distributor |
| Engine Oil Capacity | 6 quarts with filter change |
| Engine Oil Spec | SAE 5W-20 (Motorcraft) |
| Coolant Capacity | ~17.9 liters (18.9 qts / 4.7 gal) |
| Coolant Spec | Motorcraft Premium Gold (yellow) — do not mix with green |
| Fuel Tank Capacity | 19 gallons (gasoline) |
Transmission Specifications
The 2006 Town Car uses the 4R75W, same as the Crown Victoria and Grand Marquis from 2005 onward. Gear ratios and fluid spec are shared across all three Panther models. The 4R75W on the Town Car is subject to the same 2005–2006 TCC-application-in-2nd TSB that affects the Crown Vic — premature torque converter clutch lockup creating a hesitation at light throttle in the 15–30 mph range, fixed by a PCM reflash. Fluid spec is Mercon V without exception — standard Mercon and Dexron both degrade the friction material in this unit. The Town Car's rear axle is the same Ford 8.8-inch unit used across the platform, with the same lubricant requirements.
| Specification | Value |
|---|---|
| Transmission Model | Ford 4R75W 4-speed automatic |
| Type | Rear-wheel drive, 4-speed automatic with overdrive |
| 1st Gear Ratio | 2.84:1 |
| 2nd Gear Ratio | 1.55:1 |
| 3rd Gear Ratio | 1.00:1 |
| 4th Gear Ratio (OD) | 0.70:1 |
| Reverse Ratio | 2.32:1 |
| Turbine Speed Sensor | Yes — TSS (C175T pin 15) feeds PCM for TC slip monitoring |
| Fluid Type | Mercon V ATF — do not substitute Mercon or Dexron |
| Fluid Capacity | ~13.9 quarts (total system, dry fill) |
| Rear Axle | Ford 8.8 inch — Traction-Lok (limited slip) optional |
| Rear Axle Fluid | 75W-140 synthetic (LSD) or 80W-90 (standard) |
| Rear Axle Fluid Note | Add 4 oz. Motorcraft XL-3 friction modifier for Traction-Lok |
Battery Junction Box Fuse Panel Data & Info
Location: Engine bay, passenger side, behind battery | All information verified with AllData.
The Town Car's BJB shares the same under-hood location as the Crown Victoria and Grand Marquis — passenger side of the engine bay, behind the battery — but the circuit layout is meaningfully different. Without a police-package variant to support, the high-numbered maxi-fuse positions (101–118) are populated with luxury-specific feeds rather than police accessory circuits. Position 108 feeds the Power Deck-lid Module (PDM) at 40A. Positions 111 and 113 supply rear power points #1 and #2 at 20A each. Position 112 feeds the RASM air compressor at 30A. Positions 114 through 118 handle moonroof, rear cigar lighters, trunk pull-down, driver seat module, and rear heated seats — circuits that don't exist in the Crown Vic BJB at all. The relay bank also differs: the Town Car uses micro relays (201–209) and mini relays (301–304) rather than the 1/2 ISO and full ISO relay formats in the Crown Vic. The relay functions are also different — position 202 is a PCM relay and 203 is a fuel pump relay on the Town Car, whereas those slots are empty on the 2005–2006 Crown Vic. Cross-referencing Crown Vic BJB data on a Town Car will produce mismatches at multiple positions; use this post's data, not the Crown Vic sheet.
The same moisture-and-resistance failure path applies here as on any Panther BJB. Water in through a missing cover, corroded cowl drain, or direct exposure leads to corrosion on fuse legs and bus contacts, resistance builds, heat follows, and you get intermittent no-crank, blown maxi fuses, or multiple unrelated systems failing at once. The two-step fix holds: seal the water path first, then physically inspect every fuse, relay, and bus contact for oxidation or heat damage. White and green corrosion on fuse legs, melted plastic at relay sockets, or arc-burned bus bars all mean repair or replace — not clean and hope. Voltage-drop test the main BJB feeds and grounds under load after any repair. More than 0.1–0.2V across a connection means the resistance is still there.
| # | AMP | FUNCTION |
|---|---|---|
| 1 | 30A | Radio, I/P fuse 33 |
| 2 | 20A | Front power point |
| 3 | — | Not used |
| 4 | 15A | Horn |
| 5 | 20A | Fuel pump, Inertia switch |
| 6 | 20A | Right rear power point (Long Wheel Base only) |
| 7 | 30A | Front driver and front passenger heated seats |
| 8 | — | Not used |
| 9 | — | Not used |
| 10 | 10A | Rear Air Suspension Module (RASM) |
| 11 | 30A | Rear driver and passenger heated seats (Long Wheel Base only) |
| 12 | 20A | Left rear power point (Long Wheel Base only) |
| 13 | 15A | Alternator |
| 14 | 20A | Rear door cigar lighters (Long Wheel Base only) |
| 15 | — | Not used |
| 16 | — | Not used |
| 17 | — | Not used |
| 18 | — | Not used |
| 19 | 15A | MAF sensor, DPFE sensor, Fuel injectors, PCM |
| 20 | 15A | PCM, Canister vent solenoid, VMV, HEGOs |
| 21 | — | Not used |
| 22 | — | Not used |
| 23 | — | Not used |
| 24 | — | Not used |
| 101 | 50A | Ignition switch, Starter motor, I/P fuses 2, 4, 6, 8, 13, 15, 17, 24, 26 |
| 102 | 50A | Cooling fan (variable speed) |
| 103 | 40A | Blower motor |
| 104 | 40A | Heated backlight, I/P fuse 28 |
| 105 | 30A | EEC relay, I/P fuses 19, 20, Fuel pump relay coil, A/C clutch relay coil |
| 106 | 40A | ABS module |
| 107 | 40A | I/P fuse 29, Delayed accessories relay (windows, moonroof, radio) |
| 108 | 40A | Power Deck-lid Module (PDM) |
| 109 | 40A | Power decklid, Trunk pull-down/latch module |
| 110 | — | Not used |
| 111 | — | Not used |
| 112 | 40A | Ignition switch, I/P fuses 10, 12, 14, 16, 18 |
| 113 | 40A | I/P fuses 1, 3, 5, 7, 9, 31 |
| 114 | 30A | RASM compressor |
| 115 | 40A | I/P fuses 11, 19, 21, 23, 25, 27 |
| 116 | 30A | Wipers |
| 117 | 30A | Rear power seats (Long Wheel Base only) |
| 118 | 20A | ABS |
| 201 | 1/2 ISO | Horn relay |
| 202 | 1/2 ISO | PCM relay |
| 203 | 1/2 ISO | Fuel pump relay |
| 204 | 1/2 ISO | A/C clutch relay |
| 205 | — | Not used |
| 206 | 1/2 ISO | Cornering lamp ground relay |
| 207 | 1/2 ISO | Fog lamps relay |
| 208 | 1/2 ISO | Park lamp isolation relay |
| 209 | 1/2 ISO | ABS relay |
| 301 | Full ISO | Blower motor relay |
| 302 | Full ISO | Starter solenoid relay |
| 303 | Full ISO | Heated backlight relay |
| 304 | Full ISO | RASM relay |
| 401 | — | Not used |
| 501 | Diode | PCM |
| 502 | Diode | A/C clutch |
| 503 | — | Not used |
| 601 | — | Not used |
| 602 | — | Not used |
Legend
- # — Terminal Position
- ABS — Anti-lock Brake System
- ACC — Accessory
- AMP — Terminal Amperage
- DPFE — Differential Pressure Feedback EGR
- EEC — Electronic Engine Control
- FUNCTION — Circuit Function
- HEGO — Heated Exhaust Gas Oxygen sensor
- I/P — Instrument Panel
- ISO — International Standards Organization
- LWB — Long Wheel Base
- MAF — Mass Air Flow
- PCM — Powertrain Control Module
- PDM — Power Deck-lid Module
- RASM — Rear Air Suspension Module
- VMV — Vapor Management Valve
Powertrain Control Module (PCM/ECU) Data & Info
Location: Engine bay, driver's side inner fender | All information verified with AllData.
The 2006 Town Car PCM sits in the same physical location as every other Panther PCM — driver's side inner fender, single bracket bolt — and manages the same ETC drive-by-wire system through the same three-connector 150-pin harness: C175T (left), C175B (center), C175E (right). The ETC architecture is identical to the 2006 Crown Victoria: three APP sensors feeding the PCM redundant pedal-position signals through C175B, two TPS sensors on the throttle body confirming plate angle back through C175E, and the PCM directly driving the throttle motor. If any two signals disagree outside tolerance, the PCM sets an ETC fault, illuminates the wrench light, and may restrict throttle to limp-home. The main differences on the Town Car's C175T vs. the Crown Vic are in the indicator control pins: the 2006 Town Car C175T retains pin 21 as an ETC warning indicator control line (DG/LG, circuit 75) that the Crown Vic drops for 2006, and pin 33 is the anti-theft indicator at circuit 1269. Pins 35 and 36 (SCP bus) are not used on the 2006 Town Car. C175B on the Town Car is nearly identical to the Crown Vic with one notable difference: pin 3 is the A/C cycling switch signal (not the low charge protection switch), and pin 15 is not used on the 2006 model (the A/C evaporator discharge temperature sensor line from the 2005 is dropped). C175E is functionally the same as the 2006 Crown Vic, including the heated PCV control at pin 26 (YE/LB, circuit 369).
C175T handles transmission signals, downstream O2 sensor inputs, generator data, and vehicle speed. C175B handles power, grounds, the full ETC APP sensor suite, CAN bus, modulated fuel pump signal, starter relay control, A/C system, and EVAP. C175E handles all eight injector controls, all eight COP controls, crankshaft and camshaft position, knock sensors, O2 heaters, throttle motor wiring, MAP, and heated PCV. Ground integrity at C175B pins 47–50 (BK/WH, circuit 570, 18 gauge) is the first check on any PCM communication fault, transmission shift complaint, or intermittent misfire code. Voltage drop above 0.1V on any of those pins under load points to a ground problem, not a bad PCM.
Same three failure patterns to rule out on a high-mileage 2006 Town Car before condemning the PCM: (1) C175B pins 47–50 ground cluster corrosion; (2) ETC faults (P2100–P2119, wrench light) — clean the throttle bore and plate before replacing anything, carbon buildup causes enough plate binding to trigger false faults; (3) COP boot failures — cracked boots allow voltage spikes to backfeed through C175E into PCM output drivers, sustained misfires (P030X) without a boot inspection aren't a diagnosis. The 2006 Town Car PCM requires VIN programming after replacement.
C175T (BK) | LEFT (12B637)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | DB/YE | 136 | 20 | Output shaft speed (OSS) sensor signal |
| 4 | — | — | — | Not used |
| 5 | — | — | — | Not used |
| 6 | — | — | — | Not used |
| 7 | — | — | — | Not used |
| 8 | — | — | — | Not used |
| 9 | — | — | — | Not used |
| 10 | — | — | — | Not used |
| 11 | WH/YE | 925 | 20 | Electronic Pressure Control (EPC) solenoid |
| 12 | — | — | — | Not used |
| 13 | — | — | — | Not used |
| 14 | — | — | — | Not used |
| 15 | DG/WH | 970 | 20 | Turbine shaft speed (TSS) sensor signal |
| 16 | YE/BK | 1144 | 20 | Digital Transmission Range (DTR) sensor — TR1 |
| 17 | LB/BK | 1145 | 20 | Digital Transmission Range (DTR) sensor — TR2 |
| 18 | — | — | — | Not used |
| 19 | YE/LB | 1816 | 20 | Generator communication |
| 20 | — | — | — | Not used |
| 21 | DG/LG | 75 | 20 | Electronic Throttle Control (ETC) warning indicator control |
| 22 | — | — | — | Not used |
| 23 | — | — | — | Not used |
| 24 | RD/LG | 392 | 18 | Heated oxygen sensor (HO2S) #12 input |
| 25 | VT/LG | 393 | 18 | Heated oxygen sensor (HO2S) #22 input |
| 26 | — | — | — | Not used |
| 27 | RD/BK | 1268 | 20 | Digital Transmission Range (DTR) sensor — TR3A |
| 28 | WH/BK | 1143 | 20 | Digital Transmission Range (DTR) sensor — TR4 |
| 29 | OG/BK | 923 | 20 | Transmission Fluid Temperature (TFT) sensor |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | — | — | — | Not used |
| 33 | OG/RD | 1269 | 20 | Anti-theft indicator control |
| 34 | — | — | — | Not used |
| 35 | — | — | — | Not used |
| 36 | — | — | — | Not used |
| 37 | GY/BK | 679 | 20 | Vehicle speed signal |
| 38 | YE | 1817 | 20 | Generator monitor circuit |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | OG/YE | 237 | 20 | Shift solenoid A |
| 43 | VT/OG | 315 | 20 | Shift solenoid B |
| 44 | — | — | — | Not used |
| 45 | — | — | — | Not used |
| 46 | VT/YE | 126 | 20 | Torque Converter Clutch (TCC) solenoid |
| 47 | WH/BK | 389 | 18 | Heated oxygen sensor (HO2S) #12 heater |
| 48 | TN/YE | 390 | 18 | Heated oxygen sensor (HO2S) #22 heater |
| 49 | — | — | — | Not used |
| 50 | — | — | — | Not used |
C175B (BK) | CENTER (14290)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | GY/RD | 3405 | 20 | Starter relay control |
| 3 | PK/LB | 883 | 20 | A/C cycling switch signal |
| 4 | WH/LB | 3093 | 20 | Electronic Throttle Control (ETC), VREF 1 |
| 5 | TN/YE | 1283 | 20 | Accelerator pedal position (APP) sensor 1 signal |
| 6 | TN/WH | 1284 | 20 | Electronic Throttle Control (ETC), signal return |
| 7 | OG | 636 | 20 | Deactivator switch — switched power |
| 8 | — | — | — | Not used |
| 9 | RD/PK | 791 | 20 | Fuel tank pressure transducer sensor reference voltage |
| 10 | BK | 57 | 18 | Ground |
| 11 | WH/LG | 1827 | 20 | CAN bus+ |
| 12 | LB/OG | 926 | 20 | Modulated fuel pump signal |
| 13 | VT/WH | 91 | 20 | Evaporative emission (EVAP) canister vent valve control |
| 14 | — | — | — | Not used |
| 15 | — | — | — | Not used |
| 16 | — | — | — | Not used |
| 17 | WH | 3012 | 20 | Accelerator pedal position (APP) sensor 2 signal |
| 18 | — | — | — | Not used |
| 19 | LB/BK | 151 | 20 | Speed control switch reference voltage |
| 20 | YE/BK | 1799 | 20 | RDI / VEMS signal |
| 21 | DG/YE | 238 | 20 | Fuel pump monitor |
| 22 | WH/LG | 1215 | 20 | TX signal |
| 23 | PK/LG | 1828 | 20 | CAN bus− |
| 24 | LB/BK | 3091 | 20 | Electronic Throttle Control (ETC), VREF 2 |
| 25 | OG/LB | 73 | 20 | A/C clutch relay control |
| 26 | GY | 743 | 20 | Intake air temperature (IAT) sensor signal |
| 27 | TN/WH | 224 | 20 | Transmission control switch signal |
| 28 | WH/RD | 3015 | 20 | Accelerator pedal position (APP) sensor 3 signal |
| 29 | — | — | — | Not used |
| 30 | DG/OG | 848 | 20 | Speed control switch — signal return |
| 31 | WH/BK | 1154 | 20 | A/C pressure transducer sensor signal |
| 32 | LB/RD | 967 | 20 | Mass Air Flow (MAF) sensor signal |
| 33 | — | — | — | Not used |
| 34 | LG/BK | 191 | 20 | Vapor Management Valve (VMV) control |
| 35 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 36 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | BR/WH | 351 | 20 | Reference voltage |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | GY/OG | 1216 | 20 | RX signal |
| 43 | TN/LB | 968 | 20 | Mass Air Flow (MAF) sensor signal return |
| 44 | VT | 107 | 20 | Flash / EEPROM power supply |
| 45 | RD/WH | 729 | 20 | Voltage supplied at all times (overload protected) |
| 46 | YE/LG | 330 | 20 | Power steering pressure switch signal |
| 47 | BK/WH | 570 | 18 | Ground |
| 48 | BK/WH | 570 | 18 | Ground |
| 49 | BK/WH | 570 | 18 | Ground |
| 50 | BK/WH | 570 | 18 | Ground |
C175E (BK) | RIGHT (12B637)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | LG/WH | 1024 | 20 | Coil-on-plug (COP) 1 control |
| 2 | TN | 555 | 20 | Fuel injector 1 control |
| 3 | WH | 556 | 20 | Fuel injector 2 control |
| 4 | BR/YE | 557 | 20 | Fuel injector 3 control |
| 5 | BR/LB | 558 | 20 | Fuel injector 4 control |
| 6 | BR/PK | 360 | 20 | EVR solenoid signal |
| 7 | PK/OG | 1858 | 20 | Electronic Throttle Control (ETC) module signal return |
| 8 | TN/BK | 559 | 20 | Fuel injector 5 control |
| 9 | LG/OG | 560 | 20 | Fuel injector 6 control |
| 10 | TN/RD | 561 | 20 | Fuel injector 7 control |
| 11 | LB | 562 | 20 | Fuel injector 8 control |
| 12 | PK/WH | 1026 | 20 | Coil-on-plug (COP) 2 control |
| 13 | — | — | — | Not used |
| 14 | RD/OG | 229 | 20 | Engine cooling fan module control |
| 15 | — | — | — | Not used |
| 16 | — | — | — | Not used |
| 17 | — | — | — | Not used |
| 18 | YE/WH | 1857 | 20 | Electronic Throttle Control (ETC) module reference voltage |
| 19 | GY/WH | 355 | 20 | Throttle Position Sensor (TPS) signal 1 |
| 20 | YE | 1273 | 20 | Knock sensor − |
| 21 | — | — | — | Not used |
| 22 | — | — | — | Not used |
| 23 | LB/RD | 3067 | 20 | Manifold Absolute Pressure (MAP) sensor input |
| 24 | WH/PK | 1028 | 20 | Coil-on-plug (COP) 3 control |
| 25 | DB/OG | 282 | 20 | Camshaft position sensor signal |
| 26 | YE/LB | 369 | 20 | Heated PCV control |
| 27 | — | — | — | Not used |
| 28 | — | — | — | Not used |
| 29 | YE/WH | 357 | 20 | Throttle Position Sensor (TPS) signal 2 |
| 30 | GY/LB | 74 | 18 | Heated oxygen sensor (HO2S) #11 input |
| 31 | RD/BK | 94 | 18 | Heated oxygen sensor (HO2S) #21 input |
| 32 | YE/RD | 310 | 20 | Knock sensor + |
| 33 | YE/LG | 1102 | 20 | Cylinder head temperature sensor signal |
| 34 | BK/PK | 138 | 20 | Crankshaft position sensor + |
| 35 | DG/VT | 1030 | 20 | Coil-on-plug (COP) 4 control |
| 36 | LB | 1164 | 20 | Injector temperature sensor signal |
| 37 | RD/PK | 141 | 20 | Injector pressure sensor signal |
| 38 | LG/YE | 1021 | 20 | Coil-on-plug (COP) 5 control |
| 39 | OG/YE | 1025 | 20 | Coil-on-plug (COP) 6 control |
| 40 | BR/WH | 351 | 20 | Reference voltage |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | PK/LB | 1027 | 20 | Coil-on-plug (COP) 7 control |
| 43 | WH/RD | 1029 | 20 | Coil-on-plug (COP) 8 control |
| 44 | BR/LG | 352 | 20 | Differential Pressure Feedback EGR (DPFE) sensor input |
| 45 | GY/YE | 139 | 20 | Crankshaft position sensor − |
| 46 | — | — | — | Not used |
| 47 | DB/YE | 1835 | 18 | Electronic Throttle Control (ETC) motor +/− |
| 48 | OG/YE | 1836 | 18 | Electronic Throttle Control (ETC) motor +/− |
| 49 | RD/WH | 387 | 18 | Heated oxygen sensor (HO2S) #11 heater |
| 50 | YE/LB | 388 | 18 | Heated oxygen sensor (HO2S) #21 heater |
Wire Color Legend
- BK — Black
- BR — Brown
- DB — Dark Blue
- DG — Dark Green
- GY — Gray
- LB — Light Blue
- LG — Light Green
- OG — Orange
- PK — Pink
- RD — Red
- TN — Tan
- VT — Violet
- WH — White
- YE — Yellow
Central Junction Fuse Box Data & Info
Location: Driver's side compartment, under steering wheel | All information verified with AllData.
The Town Car's CJB shares the same under-dash location as the other Panther models but the circuit map reflects the Lincoln's higher equipment content. Where the Crown Victoria CJB has fuse positions dedicated to police gear, the Town Car's equivalent positions handle things like keypad entry, parking aid module, rear audio/climate, adjustable pedals, and rear heated seats. Position 8 is a good example — on the Crown Vic it routes to LCM or VAPS depending on year, but on the Town Car it feeds the rear window defrost relay, trunk pull-down module, transmission control switch, instrument cluster, and LCM all from a single 10A fuse. Position 19 handles the keypad switch, exterior mirrors, Driver Door Module, trunk pull-down, luggage compartment lid release, driver seat module, and seat adjust switch. If any of those systems misbehave simultaneously, fuse 19 is the first place to check. The BJB feeds the CJB through positions 101, 112, 113, and 115 — those maxi-fuses can kill large sections of the CJB without any visible blown fuse at the dash panel, so wide-area CJB failures always start with a BJB inspection.
Water intrusion through the cowl or firewall pass-throughs reaches the driver's footwell and CJB area on all Panthers, Town Car included. Lincoln-specific aggravating factor: the Town Car often had more harness complexity at the CJB connector due to the additional body electronics, which means more terminal surface area for corrosion to establish and more circuits to create intermittent faults when it does. The two-step fix is the same as always — eliminate the water source before touching the electrical side, then inspect connectors for corrosion, heat damage, and pin push-back. Green or black terminal faces, melted plastic, or heat-discolored pins need repair or replacement, not cleaning.
| # | AMP | FUNCTION |
|---|---|---|
| 1 | 10A | Digital Transmission Range (DTR) sensor |
| 2 | 10A | Restraints control module (14B321), Passenger Airbag Deactivation (PAD) indicator, Occupant classification sensor module |
| 3 | 10A | Radio, Audio / Navigation control unit |
| 4 | 10A | Digital Transmission Range (DTR) sensor |
| 5 | 10A | Not used (2006); 2005: Radio |
| 6 | 10A | Passive anti-theft transceiver module (15607), Ignition coil relay, PCM power diode, PCM power relay, Fuel pump relay |
| 7 | 10A | Windshield wiper motor (17508) |
| 8 | 10A | Rear window defrost relay, Trunk pull-down module, Transmission control switch, Instrument cluster, Lighting Control Module (LCM) |
| 9 | 7.5A | Lighting Control Module (LCM), Electrochromic inside mirror unit (17700), Exterior rear-view mirror switch, Door lock switch driver side and passenger side, Overhead console, Rear audio/climate control module, Seat heater switch driver side, Seat heater switch passenger side, Seat heater switch left rear, Seat heater switch right rear |
| 10 | 15A | Multi-function switch (13K359) |
| 11 | 10A | Air suspension module (3C142) |
| 12 | 10A | Lighting Control Module (LCM) |
| 13 | 10A | Instrument cluster, Parking Aid Module (PAM) (15K866) |
| 14 | 15A | Adjustable pedal switch |
| 15 | 10A | Electronic Automatic Temperature Control (EATC) module (19980) |
| 16 | 20A | Data Link Connector (DLC) (14489), Cigar lighter front (15055) |
| 17 | 10A | ABS control module (2C219); 2005: also Heated PVC |
| 18 | 15A | Lighting Control Module (LCM) |
| 19 | 10A | Keypad switch assembly, Exterior rear-view mirror switch, Driver Door Module, Trunk pull-down module, Luggage compartment lid release switch, Driver seat module (14C718), Seat adjust switch driver side front (14A701), Door lock switch driver side and passenger side |
| 20 | 10A | Lighting Control Module (LCM) |
| 21 | 10A | Instrument cluster, Autolamp sensor, Clock; 2005: also Overhead console |
| 22 | 10A | Lighting Control Module (LCM) |
| 23 | 10A | Lighting Control Module (LCM) |
| 24 | 15A | Lighting Control Module (LCM), Multi-function switch |
| 25 | 10A | Brake pedal position switch (13480), Deactivator switch |
| 26 | 15A | Lighting Control Module (LCM) |
| 27 | 10A | Electronic Automatic Temperature Control (EATC) module (19980) |
| 28 | 10A | Filter |
| 29 | 15A | Multi-function switch (13K359) |
| 30 | 15A | Multi-function switch (13K359) |
| 31 | 10A | Low charge protection switch, Heated seat module, Heated seat module left rear and right rear |
| 32 | 10A | Exterior rear-view mirror left, Exterior rear-view mirror right |
| 33 | 15A | Radio, CD changer (18D806), Audio/navigation control unit, Navigation module |
| R | RELAY | Rear window defrost relay (C2021) |
Legend
- # — Terminal Position
- ABS — Anti-lock Brake System
- ACC — Accessory
- AMP — Terminal Amperage
- DDM — Driver's Door Module
- DLC — Data Link Connector
- DTR — Digital Transmission Range
- EATC — Electronic Automatic Temperature Control
- FUNCTION — Circuit Function
- I/P — Instrument Panel
- LCM — Lighting Control Module
- MFS — Multi-Function Switch
- PAD — Passenger Airbag Deactivation
- PAM — Parking Aid Module
- PATS — Passive Anti-Theft System
- PCM — Powertrain Control Module
- R — Relay
Known Issues & TSB Reference
The items below are documented issues Ford/Lincoln acknowledged for the 2006 Town Car through Technical Service Bulletins (TSBs), extended warranty coverage, or well-established pattern failures. Full TSB text is available through ALLDATA, Mitchell1, or your dealer's service department.
4R75W — TCC Application in 2nd Gear (Hesitation / Lack of Power)
Affected: 2005–2006 Lincoln Town Car, Ford Crown Victoria, Mercury Grand Marquis. Some vehicles exhibit a stumble or lack of power shortly after acceleration from a stop, most noticeable at light throttle in the 15–30 mph range. The cause is premature Torque Converter Clutch (TCC) lockup in 2nd gear. The fix is a PCM reflash. If a 2006 Town Car hesitates in that speed range without misfire codes, start here.Reference: Ford TSB — 4R75W TCC Application in 2nd Gear, 2005–2006 Panther platform vehicles
4R75W — Forward Clutch Slipping / Metal in Fluid
Affected: 2005–2006 Ford vehicles with 4R75W. Excessive slipping across all forward gears, sometimes accompanied by metallic particles in the transmission fluid. Fix is forward clutch drum replacement plus PCM reflash (program 06B06). Dark or metallic fluid on a slipping 2006 Town Car means start with the forward clutch before evaluating anything else.Reference: Ford TSB — 4R75W Forward Clutch Slipping, 2005–2006 Ford vehicles
Electronic Throttle Control (ETC) — Diagnosis Procedure
Affected: 2005–2006 Town Car and other ETC-equipped Ford/Lincoln/Mercury vehicles. Ford's revised PC/ED manual notes that the ETC_ACT and ETC_DSD PIDs should not be used to diagnose electronic throttle body (ETB) concerns. Before replacing the throttle body or PCM on a wrench-light complaint: clean the throttle bore and plate, inspect APP sensor connectors at C175B, and verify TPS1 (C175E pin 19) and TPS2 (C175E pin 29) are tracking each other within spec.Reference: TSB — ETC Diagnostic Procedure Revision, 2005–2006 model year vehicles
Coil-on-Plug (COP) Ignition — Misfire Diagnosis
Affected: 2006 Town Car and other 2006 Ford/Lincoln/Mercury COP-equipped vehicles. The 2006 Town Car uses 8 individual DG-508 coils — no distributor, each coil fires directly to its plug. Cracked or carbon-tracked boots (especially in high-heat valley positions), weak aging coils, and plug-to-boot gap migration are the common patterns. A bad COP can set P030X codes and, if sustained, backfeed voltage spikes through C175E into PCM output drivers. Always inspect boots and plugs together — swapping coils without checking plugs just relocates the problem.Reference: TSB — COP Ignition Misfire Diagnostic Tips, 2006 model year vehicles
Air Suspension — Compressor / RASM Failures
Affected: 2003–2011 Lincoln Town Car (standard equipment). The Town Car's rear air suspension is a known high-mileage failure point. The air compressor (fed by BJB #114 at 30A through the RASM relay at position 302, controlled by the RASM module at CJB #11) can fail from moisture ingestion — the intake filter sits in the wheel well and can draw in water in wet conditions. Symptoms are sagging rear end, compressor running continuously, or RASM faults. Before condemning the compressor, check the intake filter and lines for water contamination. Also check that BJB #114 and CJB #11 are intact; a blown fuse here is often misdiagnosed as a failed compressor.Reference: Community-documented pattern failure — 2003–2011 Lincoln Town Car air suspension
Scheduled Maintenance Intervals
The intervals below are from Ford's Normal Schedule as published in the Scheduled Maintenance Guide covering the Crown Victoria, Grand Marquis, and Town Car. Normal schedule applies to typical everyday driving. The Town Car, if used for livery or taxi service, follows the Special Operating Conditions schedule — oil every 3,000 miles / 3 months, ATF every 30,000 miles. The rear air suspension system on the Town Car has no specific service interval but should be inspected for line cracks, dried seals, and compressor filter condition at every major service given its exposure to road spray.
| Service Item | Normal Interval | Notes |
|---|---|---|
| Engine Oil & Filter | Every 5,000 miles or 6 months | SAE 5W-20 — 6 qts with filter. Livery/taxi: every 3,000 mi or 3 months |
| Tire Rotation | Every 5,000 miles | Inspect for wear at each rotation |
| Engine Air Filter | Every 30,000 miles | Motorcraft FA-1783 — replace sooner in dusty conditions |
| Fuel Filter | Every 30,000 miles | Motorcraft FG-986B — heavy use: every 15,000 miles |
| Spark Plugs | Every 100,000 miles | Motorcraft SP-413 — gapped at 0.054 in. Do not reuse if COP boots are cracked |
| PCV Valve | Every 100,000 miles | Replace at same interval as plugs |
| Serpentine Drive Belt | Inspect at 100,000 miles | Motorcraft JK6-926 — replace if cracked, glazed, or fraying |
| Engine Coolant | First change at 6 years or 100,000 miles | Motorcraft Premium Gold (yellow) — then every 3 years / 50,000 miles after |
| Automatic Transmission Fluid | Inspect at 15,000 mi — change at 150,000 miles | Mercon V only. Livery/heavy use: every 30,000 miles |
| Brake Fluid | As needed / inspect annually | DOT 3 — replace if dark or boiling point degraded |
| Brake System Inspection | Every 15,000 miles | Pads, rotors, lines, hoses, parking brake |
| Rear Axle Lubricant | Inspect — synthetic fill considered "for life" | Livery: replace every 100,000 miles. Add XL-3 friction modifier for Traction-Lok |
| Power Steering Fluid | Check at every oil change | Mercon ATF — ~2 pints capacity |
| Air Suspension Lines / Filter | Inspect at every major service | Check compressor intake filter, air lines, and rear air bag condition for cracks or leaks |
| Cooling System Hoses | Inspect at every major service | Replace heater hose assembly at first sign of seeping — Motorcraft KH428 |
Other Lincoln Town Car Years
- 2003 Lincoln Town Car
- 2004 Lincoln Town Car
- 2005 Lincoln Town Car
- 2006 Lincoln Town Car — You are here
- 2007 Lincoln Town Car
- 2008 Lincoln Town Car
- 2009 Lincoln Town Car
- 2010 Lincoln Town Car
- 2011 Lincoln Town Car
Other Panther Platform Models
Data Disclaimer & Limitation of Liability
Read before using any data published on this site
Informational use only. All fuse assignments, relay positions, wire color codes, pin assignments, circuit numbers, connector identifiers, engine specifications, transmission specifications, torque values, maintenance intervals, and technical service bulletin references published on this site are provided for informational and reference purposes only. This data is not a substitute for a factory Ford, Lincoln, or Mercury service manual, an ALLDATA or Mitchell1 subscription, or the judgment of a qualified, licensed automotive technician.
No warranty. Data provided as-is. Riot Mind Studios, LLC makes no representations or warranties of any kind — express, implied, or statutory — regarding the completeness, accuracy, currency, or fitness for a particular purpose of any data published on this site. All information is provided strictly on an "as-is" and "as-available" basis. We do not warrant that any data point is free from error, omission, or misprint. We do not warrant that this data reflects the current production configuration of any specific vehicle.
Vehicle condition and prior modifications. The Panther Platform vehicles covered by this database (2003–2011 Ford Crown Victoria, Lincoln Town Car, Mercury Grand Marquis, and Mercury Marauder) are aging vehicles with decades of potential service history. Individual vehicles may have been subject to dealer modifications, police upfitter conversions, aftermarket electrical work, wiring repairs, fuse upgrades, or component substitutions that are not reflected in factory documentation or in the data published here. You are responsible for verifying all data against the actual condition of your specific vehicle before performing any repair, diagnostic test, or electrical work.
Model year and trim variation. Fuse assignments, relay types, PCM pin functions, and circuit configurations vary across model years, between trim levels (LX, P71/Police Interceptor, Executive, Signature, GS, LS, HPP, etc.), and in some cases between build dates within the same model year. Data that is accurate for one configuration may be incorrect or inapplicable for another. Always cross-reference this database against a source that is specific to your vehicle's model year, trim level, and build date.
Limitation of liability. To the fullest extent permitted by applicable law, Riot Mind Studios, LLC, its owner, affiliates, and any contributors shall not be liable for any direct, indirect, incidental, special, consequential, or punitive damages arising out of or related to your use of, or inability to use, any data, specification, schematic reference, or other content published on this site. This includes, without limitation: personal injury; vehicle damage; electrical damage; fire; failed emissions or safety inspections; failed diagnostic procedures; incorrect repairs; financial loss; towing costs; or damage to tools or property. Your use of this data is entirely at your own risk.
Professional consultation. Always consult a qualified technician before performing work on safety-critical systems including but not limited to: anti-lock brakes (ABS), supplemental restraint systems (SRS/airbags), fuel delivery, ignition, emissions-related components, and any circuit connected to the Powertrain Control Module (PCM). Incorrect wiring or fuse substitution on these systems can cause personal injury, fire, or permanent damage to vehicle electronics.
Affiliate links. Some links on this site are Amazon affiliate links. Riot Mind Studios, LLC earns a small commission on qualifying purchases at no additional cost to you. Affiliate links do not influence the data or technical content published on this site.
Third-party sources. Some data on this site is derived or cross-referenced from third-party sources including Ford Motor Company factory documentation, ALLDATA, and community-sourced vehicle databases. Riot Mind Studios, LLC does not represent Ford Motor Company, Lincoln, Mercury, or any affiliated brand in any capacity. All trademarks, model names, and manufacturer references are the property of their respective owners and are used here for identification purposes only.
