2011 Lincoln Town Car Info Systems & Data Sheets
The 2011 Lincoln Town Car is the final production year of the Panther platform's body-on-frame full-size sedan — a run that started in 1979 and ended here. Under the hood it's the same 4.6L SOHC 2-valve "Romeo" V8 that's carried every Town Car since 2003, rated at 239 hp at 4,900 rpm and 287 lb-ft of torque at 4,100 rpm, backed by the 4R75W 4-speed automatic. Output figures are slightly above the Crown Victoria and Grand Marquis — the Town Car's intake tuning and exhaust routing are specific to this application. Drive-by-wire ETC has been standard since 2005. What makes the 2011 electrically distinct from its platform siblings is the Town Car's heavier equipment load: air suspension compressor, power deck-lid module, adjustable pedals, rear heated seats, dual rear power points, and the full Driver Seat Module (DSM) and Driver Door Module (DDM) suite. It also carries the rear air suspension module (RASM) and its associated 30A compressor relay — a load the Crown Victoria dropped from civilian trim years earlier. The PCM harness runs three connectors: C175T (left, 50 pins), C175B (center, 50 pins), and C175E (right, 70 pins). The C175E pin count on the Town Car is higher than on the Crown Vic — the extra pins carry the additional injector, ignition, and sensor circuits needed to manage this application. Trim for 2011 is Executive, Signature, Signature Limited, and Signature L (long wheelbase).
Download Your Schematics:
- 2011 Lincoln Town Car Battery Junction Fuse Box Schematic Data Sheet
- 2011 Lincoln Town Car Powertrain Control Module Schematic Data Sheet
- 2011 Lincoln Town Car Central Junction Box Schematic Data Sheet
Resources:
- Ford OBD-2 Diagnostic Trouble Codes List
- 2003–2011 Panther Platform Resources & Manuals List
- Label Installation Guide
Labels:
In this post:
- Engine Specifications
- Transmission Specifications
- Battery Junction Box Fuse Panel Data & Info
- Powertrain Control Module Data & Info
- Central Junction Fuse Box Data & Info
- Trim Level Fuse Differences
- Known Issues & TSB Reference
- Scheduled Maintenance Intervals
Engine Specifications
The 2011 Town Car runs Ford's 4.6L 2-valve SOHC "Romeo" V8 — same block, same displacement, same bore and stroke as every Panther platform car since 2003. The Romeo casting (Romeo, Michigan plant) is specific to the Crown Vic, Town Car, and Grand Marquis application; it is not interchangeable with the Windsor-cast 4.6 used in Mustangs and trucks without significant parts changes. Output on the Town Car is rated slightly higher than the Crown Victoria civilian — 239 hp versus 224 hp — due to application-specific intake tuning and dual exhaust routing. Drive-by-wire ETC has been standard on all Panthers since 2005. The Town Car's PCM calibration is its own file — do not flash or swap PCMs across models even within the same year without confirming the exact part number match. All figures below are SAE net.
| Specification | Value |
|---|---|
| Engine Family | Ford Modular V8 — Romeo cast |
| Displacement | 4.6L (4,601 cc / 280.8 cu in) |
| Configuration | V8, 90° — SOHC, 2 valves per cylinder (16 total) |
| Bore × Stroke | 90.2 mm × 90.0 mm (3.55 in × 3.54 in) |
| Compression Ratio | 9.4:1 |
| Horsepower | 239 hp @ 4,900 rpm (SAE net) |
| Torque | 287 lb-ft @ 4,100 rpm (SAE net) |
| Redline | ~5,550 rpm |
| Fuel Type | Unleaded — 87 octane minimum (regular) |
| Fuel Injection | Sequential Multi-Port Fuel Injection (SEFI) |
| Throttle Control | Electronic (Drive-By-Wire / ETC) — standard since 2005 |
| Ignition | Coil-on-plug (COP) — 8 individual coils, no distributor |
| Engine Oil Capacity | 6 quarts with filter change |
| Engine Oil Spec | SAE 5W-20 (Motorcraft) |
| Coolant Capacity | ~17.9 liters (18.9 qts / 4.7 gal) |
| Coolant Spec | Motorcraft Premium Gold (yellow) — do not mix with green |
| Fuel Tank Capacity | 19 gallons (gasoline) |
Transmission Specifications
The 2011 Town Car uses the 4R75W — the same 4-speed automatic carried across all 2005–2011 Panther models. The 4R75W replaced the 4R70W at the 2005 model year transition when ETC went platform-wide; it added the turbine shaft speed (TSS) sensor that feeds C175T pin 15, allowing the PCM to track torque converter slip in real time and manage TCC lockup more precisely. The Town Car's 4R75W calibration is matched to the higher-torque engine output — fluid spec is Mercon V for all 2003+ Panthers, no exceptions. Do not use standard Mercon or Dexron; both will degrade the friction material. Some 2009+ units shipped as "filled for life" sealed cases with no dipstick — fluid level check on those requires a lift and a drain/fill plug procedure. If you're experiencing erratic shifting or TCC shudder, read the DTCs before replacing anything — the PCM stores specific transmission-side codes (P07xx range) that point directly to the solenoid or sensor at fault.
| Specification | Value |
|---|---|
| Transmission Model | Ford 4R75W 4-speed automatic |
| Type | Rear-wheel drive, 4-speed automatic with overdrive |
| 1st Gear Ratio | 2.84:1 |
| 2nd Gear Ratio | 1.55:1 |
| 3rd Gear Ratio | 1.00:1 |
| 4th Gear Ratio (OD) | 0.70:1 |
| Reverse Ratio | 2.32:1 |
| Torque Capacity | ~700 Nm |
| Turbine Speed Sensor | Yes — TSS (C175T pin 15) feeds PCM for TC slip monitoring |
| Fluid Spec | Mercon V — do not substitute Mercon or Dexron |
| Fluid Capacity | ~13.1 qts total fill (dry) — pan service approx. 5–6 qts |
| Rear Axle | Ford 8.8 inch — Traction-Lok (limited slip) optional |
| Rear Axle Fluid | 75W-140 synthetic (Traction-Lok) or 80W-90 (standard) |
| Rear Axle Fluid Note | Add 4 oz. Motorcraft XL-3 friction modifier for Traction-Lok |
Battery Junction Box Fuse Panel Data & Info
Location: Engine bay, passenger side, behind battery | All information verified with AllData.
The Battery Junction Box (BJB) is the under-hood high-current distribution center — the first hard protection point between the battery and alternator output and everything downstream in the car. On the 2011 Town Car it carries the primary high-current feeds: starter relay (30A), dual cooling fan (50A), two main I/P fuse box feeds (103 and 104, both 50A), ABS pump (40A), rear defroster relay (40A), blower relay (40A), Power Deck-lid Module (40A), and RASM air compressor relay (30A). The Town Car's BJB load profile is heavier than the Crown Vic civilian because it's running a full air suspension compressor, deck-lid pull-down motor, and dual rear power points as standard equipment — those are all loads the Crown Vic doesn't carry. Relays 201–209 are Micro Relay format, 301–304 are Mini Relay. Positions 401, 207, and 208 are unpopulated on all 2007–2011 Town Cars. If you're working on a car with fog lamps (relay 202 populated 2007 only), verify the year before sourcing replacements — 2008–2011 leaves that slot empty. Diodes 501–503 handle back-EMF suppression; 501 is unused 2008–2011, 502 protects against reverse battery, and 503 covers the horn and door latch circuits.
The same moisture and heat failure modes that kill Crown Vic BJBs hit Town Cars just as hard — and the added relay and maxi-fuse count gives corrosion more surface area to work with. Water gets in through a damaged or missing cover, degraded cowl drainage, or direct spray during washing. Once it contacts the bus bar and fuse legs, resistance builds, heat follows, and you start seeing intermittent no-crank, random maxi-fuse failures, charging irregularities, or multiple unrelated systems going down at once. The deck-lid pulldown and RASM circuits are high-cycling loads that accelerate terminal wear at their respective relay sockets — if you're seeing these systems fail intermittently, pull and inspect those relay sockets before buying parts. Fix procedure is the same as any Panther BJB failure: eliminate the water source first, inspect every fuse and relay terminal for corrosion or heat discoloration, and repair or replace damaged contacts. After repairs, voltage-drop test the main BJB feeds and grounds under load — more than 0.1–0.2V drop across a connection means resistance is still present and the heat will return.
| # | AMP | FUNCTION |
|---|---|---|
| 1 | 30A | Ignition switch |
| 2 | 20A | 2007: Moonroof, rear heated seats; 2008–2011: Rear heated seats |
| 3 | 10A | Powertrain Control Module (PCM) keep alive power and canister vent |
| 4 | 20A | Fuel relay feed |
| 5 | 20A | Instrument panel power point |
| 6 | 15A | Alternator regulator |
| 7 | 30A | PCM relay feed |
| 8 | 20A | Driver's Door Module (DDM) |
| 9 | 15A | Ignition coil relay feed |
| 10 | 20A | Horn relay feed |
| 11 | 15A | A/C clutch relay feed |
| 12 | 20A | Audio |
| 13 | 10A | Rear Air Suspension Module (RASM) |
| 14 | 20A | Stop lamp switch |
| 15 | 15A | Lumbar, fuel door |
| 16 | 20A | Heated seats |
| 17 | — | Not used |
| 18 | — | Not used |
| 19 | 15A | Injectors |
| 20 | 15A | PCM |
| 21 | 15A | Powertrain loads and sensors |
| 22 | — | Not used |
| 23 | 10A | Heated mirrors |
| 24 | — | Not used |
| 101 | 40A | Blower relay feed |
| 102 | 50A | Cooling fan |
| 103 | 50A | Instrument panel (I/P) fuse box feed #1 |
| 104 | 50A | Instrument panel (I/P) fuse box feed #2 |
| 105 | 30A | Starter relay feed |
| 106 | 40A | Anti-lock Brake System (ABS) module (pump) |
| 107 | 40A | Rear defroster relay feed |
| 108 | 40A | Power Deck-lid Module (PDM) |
| 109 | 20A | ABS module (valves) |
| 110 | 30A | Wiper module |
| 111 | 20A | Rear power point #1 (left) |
| 112 | 30A | RASM (air compressor) |
| 113 | 20A | Rear power point #2 (right) |
| 114 | 20A | Instrument panel fuse box feed #3 |
| 115 | 20A | Rear cigar lighters |
| 116 | 30A | Deck-lid pulldown module |
| 117 | 20A | 2007: Fog lamps; 2008: Not used; 2009–2011: Cigar lighter |
| 118 | — | Not used |
| 201 | Micro Relay | A/C clutch |
| 202 | Micro Relay | 2007: Fog lamps; 2008–2011: Not used |
| 203 | Micro Relay | Ignition coil |
| 204 | Micro Relay | PCM |
| 205 | — | Not used |
| 206 | Micro Relay | Fuel |
| 207 | — | Not used |
| 208 | — | Not used |
| 209 | Micro Relay | Horn |
| 301 | Mini Relay | Starter |
| 302 | Mini Relay | RASM (air compressor) |
| 303 | Mini Relay | Blower |
| 304 | Mini Relay | Rear defroster |
| 401 | — | Not used |
| 501 | Diode | 2007: A/C clutch; 2008–2011: Not used |
| 502 | Diode | Reverse battery |
| 503 | Diode | Horn, door latch |
| 601 | 20A Circuit Breaker | Power seats, driver seat module |
| 602 | 20A Circuit Breaker | 2007: Delayed accessory relay — windows, moonroof, audio, navigation; 2008–2011: Delayed accessory relay — windows, audio |
Legend
- # — Terminal Position
- ABS — Anti-lock Brake System
- AMP — Terminal Amperage
- CB — Circuit Breaker
- DDM — Driver's Door Module
- EATC — Electronic Automatic Temperature Control
- FUNCTION — Circuit Function
- I/P — Instrument Panel
- LCM — Lighting Control Module
- PCM — Powertrain Control Module
- PDM — Power Deck-lid Module
- RASM — Rear Air Suspension Module
Powertrain Control Module (PCM/ECU) Data & Info
Location: Engine bay, driver's side inner fender | All information verified with AllData.
The PCM on the 2011 Lincoln Town Car manages engine and transmission operation through three 50–70 pin connectors on the driver's side inner fender. C175T (left, 12B637) handles transmission signals — DTR sensor inputs, solenoids A and B, TCC, EPC, TSS, and the rear HO2S bank. C175B (center, 14290) is the communication and power bus: CAN high and low (pins 11 and 23), APP sensor inputs, vehicle speed, starter relay control, fuel pump driver control, and the four PCM ground points at pins 47–50 (BK/WH, circuit 570, 18ga). C175E (right, 12B637) is the largest connector at 70 pins and covers all eight coil-on-plug outputs, all eight fuel injector outputs, the ETC motor +/−, throttle position sensors 1 and 2, MAF sensor, front HO2S inputs and heaters, crank and cam position sensors, cylinder head temperature, and the EGR-related sensors. The 2011 Town Car's C175T pin 21 is not used — this position carried the ETC warning indicator control signal on 2005 Town Cars only and went dark from 2006 forward. C175B pin 8 on 2009–2011 Town Cars carries the traction control switch on/off signal (GY, circuit 959) — absent on earlier years. Confirm connector identity before probing; C175T and C175E share the same 12B637 part number but carry completely different circuits.
Diagnosing PCM-related issues on the 2011 Town Car starts with pulling DTCs — the PCM stores specific codes for every sensor input and actuator output it monitors. True PCM failure is uncommon. Before condemning the module, verify the basics: BJB fuse 7 (PCM relay feed, 30A), BJB fuse 3 (PCM keep alive, 10A), C175B ground pins 47–50, and the physical connector condition at all three C175 connectors. Corroded or pushed-back pins at C175B pins 47–50 kill the module's ground reference and produce seemingly random fault behavior across multiple systems. If a PCM replacement is required, programming uses Ford IDS or a J2534 pass-thru device — the module must be programmed to the vehicle's VIN, PATS keys, and immobilizer data before it will start the engine. An unprogrammed PCM will crank but not fire.
C175T (BK) | LEFT (12B637)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | DB/YE | 136 | 20 | Output shaft speed (OSS) sensor signal |
| 4 | — | — | — | Not used |
| 5 | — | — | — | Not used |
| 6 | — | — | — | Not used |
| 7 | — | — | — | Not used |
| 8 | — | — | — | Not used |
| 9 | — | — | — | Not used |
| 10 | — | — | — | Not used |
| 11 | WH/YE | 925 | 20 | Electronic pressure control (EPC) solenoid |
| 12 | — | — | — | Not used |
| 13 | — | — | — | Not used |
| 14 | — | — | — | Not used |
| 15 | DG/WH | 970 | 20 | Turbine shaft speed (TSS) sensor signal |
| 16 | YE/BK | 1144 | 20 | Digital transmission range (DTR) sensor, TR1 |
| 17 | LB/BK | 1145 | 20 | Digital transmission range (DTR) sensor, TR2 |
| 18 | — | — | — | Not used |
| 19 | — | — | — | Not used |
| 20 | — | — | — | Not used |
| 21 | — | — | — | Not used |
| 22 | — | — | — | Not used |
| 23 | — | — | — | Not used |
| 24 | RD/LG | 392 | 18 | Heated oxygen sensor (HO2S) #12 input |
| 25 | VT/LG | 393 | 18 | Heated oxygen sensor (HO2S) #22 input |
| 26 | — | — | — | Not used |
| 27 | RD/BK | 1268 | 20 | Digital transmission range (DTR) sensor, TR3A |
| 28 | WH/BK | 1143 | 20 | Digital transmission range (DTR) sensor, TR4 |
| 29 | OG/BK | 923 | 20 | Transmission fluid temperature (TFT) sensor |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | OG/RD | 1269 | 20 | Anti-theft indicator control |
| 33 | — | — | — | Not used |
| 34 | — | — | — | Not used |
| 35 | — | — | — | Not used |
| 36 | — | — | — | Not used |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | OG/YE | 237 | 20 | Shift solenoid A |
| 43 | VT/OG | 315 | 20 | Shift solenoid B |
| 44 | — | — | — | Not used |
| 45 | — | — | — | Not used |
| 46 | VT/YE | 126 | 20 | Torque converter clutch (TCC) solenoid |
| 47 | WH/BK | 389 | 18 | Heated oxygen sensor (HO2S) #12 heater |
| 48 | TN/YE | 390 | 18 | Heated oxygen sensor (HO2S) #22 heater |
| 49 | — | — | — | Not used |
| 50 | — | — | — | Not used |
C175B (BK) | CENTER (14290)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | GY/BK | 679 | 20 | Vehicle speed signal |
| 2 | GY/RD | 3405 | 20 | Starter relay control |
| 3 | RD/PK | 791 | 20 | Fuel tank pressure transducer sensor signal |
| 4 | WH/LB | 3093 | 20 | Accelerator pedal position sensor 1 reference voltage |
| 5 | TN/YE | 1283 | 20 | Accelerator pedal position signal |
| 6 | TN/WH | 1284 | 20 | Accelerator pedal position signal return 2 |
| 7 | — | — | — | Not used |
| 8 | GY | 959 | 20 | Traction control switch, on/off signal |
| 9 | OG | 636 | 18 | Deactivator switch signal |
| 10 | BK | 57 | 18 | Ground |
| 11 | WH/LG | 1827 | 20 | HS CAN+ |
| 12 | LB/OG | 926 | 20 | Modulated fuel pump signal |
| 13 | VT/WH | 91 | 20 | EVAP canister vent control solenoid control |
| 14 | OG/LB | 73 | 20 | A/C clutch relay control |
| 15 | PK/LB | 883 | 20 | A/C cycling switch signal |
| 16 | — | — | — | Not used |
| 17 | WH | 3012 | 20 | Accelerator pedal position 2 signal |
| 18 | — | — | — | Not used |
| 19 | LB/BK | 151 | 20 | Speed control switch reference voltage |
| 20 | YE/BK | 1799 | 20 | RDI / VEMS signal |
| 21 | DG/YE | 238 | 20 | Fuel pump monitor |
| 22 | — | — | — | Not used |
| 23 | PK/LG | 1828 | 20 | HS CAN− |
| 24 | LB/BK | 3091 | 20 | Accelerator pedal position sensor reference voltage 2 |
| 25 | — | — | — | Not used |
| 26 | WH/BK | 1154 | 20 | A/C pressure transducer sensor signal |
| 27 | — | — | — | Not used |
| 28 | WH/RD | 3015 | 20 | Accelerator pedal position 3 signal |
| 29 | TN/WH | 224 | 20 | Transmission control switch signal |
| 30 | DG/OG | 848 | 20 | Speed control switch, signal return |
| 31 | WH/LG | 1215 | 20 | TX signal |
| 32 | YE/LB | 1816 | 20 | Generator communication |
| 33 | — | — | — | Not used |
| 34 | YE/LG | 330 | 20 | Power steering pressure switch signal |
| 35 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 36 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | BR/WH | 351 | 20 | Reference voltage |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | GY/OG | 1216 | 20 | RX signal |
| 43 | — | — | — | Not used |
| 44 | VT | 107 | 20 | Flash / EEPROM power supply |
| 45 | RD/WH | 729 | 20 | Voltage supplied at all times (overload protected) |
| 46 | — | — | — | Not used |
| 47 | BK/WH | 570 | 18 | Ground |
| 48 | BK/WH | 570 | 18 | Ground |
| 49 | BK/WH | 570 | 18 | Ground |
| 50 | BK/WH | 570 | 18 | Ground |
C175E (BK) | RIGHT (12B637)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | — | — | — | Not used |
| 4 | — | — | — | Not used |
| 5 | YE | 1817 | 20 | Generator monitor control |
| 6 | LG/BK | 191 | 20 | EVAP canister purge control |
| 7 | RD/OG | 229 | 20 | Engine cooling fan motor control |
| 8 | — | — | — | Not used |
| 9 | WH/RD | 1029 | 20 | Coil-on-plug (COP) 8 control |
| 10 | LG/YE | 1021 | 20 | Coil-on-plug (COP) 5 control |
| 11 | PK/WH | 1026 | 20 | Coil-on-plug (COP) 2 control |
| 12 | WH/PK | 1028 | 20 | Coil-on-plug (COP) 3 control |
| 13 | — | — | — | Not used |
| 14 | DG/VT | 1030 | 20 | Coil-on-plug (COP) 4 control |
| 15 | OG/YE | 1025 | 20 | Coil-on-plug (COP) 6 control |
| 16 | PK/LB | 1027 | 20 | Coil-on-plug (COP) 7 control |
| 17 | LG/WH | 1024 | 20 | Coil-on-plug (COP) 1 control |
| 18 | — | — | — | Not used |
| 19 | LB | 1164 | 20 | Injector temperature sensor signal |
| 20 | — | — | — | Not used |
| 21 | BR/LG | 352 | 20 | Differential pressure feedback EGR (DPFE) sensor input |
| 22 | GY | 743 | 20 | Intake air temperature (IAT) sensor signal |
| 23 | — | — | — | Not used |
| 24 | — | — | — | Not used |
| 25 | LB/RD | 967 | 20 | Mass air flow (MAF) sensor signal |
| 26 | TN/LB | 968 | 20 | Mass air flow (MAF) sensor signal return |
| 27 | — | — | — | Not used |
| 28 | GY/LB | 74 | 18 | Heated oxygen sensor (HO2S) #11 input |
| 29 | RD/BK | 94 | 18 | Heated oxygen sensor (HO2S) #21 input |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | RD/PK | 141 | 20 | Injector pressure sensor signal |
| 33 | — | — | — | Not used |
| 34 | DB/YE | 1835 | 20 | Electronic Throttle Control (ETC) motor + |
| 35 | WH | 556 | 20 | Fuel injector 2 control |
| 36 | BR/LB | 558 | 20 | Fuel injector 4 control |
| 37 | LG/OG | 560 | 20 | Fuel injector 6 control |
| 38 | LB | 562 | 20 | Fuel injector 8 control |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | YE/LG | 1102 | 20 | Cylinder head temperature sensor signal |
| 42 | — | — | — | Not used |
| 43 | — | — | — | Not used |
| 44 | — | — | — | Not used |
| 45 | DB/OG | 282 | 20 | Camshaft position sensor signal |
| 46 | GY/YE | 139 | 20 | Crankshaft position sensor − |
| 47 | BK/PK | 138 | 20 | Crankshaft position sensor + |
| 48 | YE | 1273 | 20 | Knock sensor − |
| 49 | YE/RD | 310 | 20 | Knock sensor + |
| 50 | — | — | — | Not used |
| 51 | OG/YE | 1836 | 20 | Electronic Throttle Control (ETC) motor − |
| 52 | TN | 555 | 20 | Fuel injector 1 control |
| 53 | BR/YE | 557 | 20 | Fuel injector 3 control |
| 54 | TN/BK | 559 | 20 | Fuel injector 5 control |
| 55 | TN/RD | 561 | 20 | Fuel injector 7 control |
| 56 | — | — | — | Not used |
| 57 | BR/WH | 351 | 20 | Reference voltage |
| 58 | GY/RD | 359 | 20 | Signal return |
| 59 | PK/OG | 1858 | 20 | Electronic Throttle Control module signal return |
| 60 | YE/WH | 357 | 20 | Throttle position (TPS) sensor signal 2 |
| 61 | GY/WH | 355 | 20 | Throttle position (TPS) sensor signal 1 |
| 62 | LB/RD | 3067 | 20 | Manifold absolute pressure (MAP) sensor input |
| 63 | BR/PK | 360 | 20 | EVR solenoid signal |
| 64 | — | — | — | Not used |
| 65 | — | — | — | Not used |
| 66 | YE/WH | 1857 | 20 | Electronic Throttle Control module reference voltage |
| 67 | — | — | — | Not used |
| 68 | — | — | — | Not used |
| 69 | RD/WH | 387 | 18 | Heated oxygen sensor (HO2S) #11 heater |
| 70 | YE/LB | 388 | 18 | Heated oxygen sensor (HO2S) #21 heater |
Wire Color Legend
- BK — Black
- BR — Brown
- DB — Dark Blue
- DG — Dark Green
- GY — Gray
- LB — Light Blue
- LG — Light Green
- OG — Orange
- PK — Pink
- RD — Red
- TN — Tan
- VT — Violet
- WH — White
- YE — Yellow
Central Junction Fuse Box Data & Info
Location: Driver's side compartment, under steering wheel | All information verified with AllData.
The Central Junction Box (CJB) on the 2011 Town Car is the interior fuse and relay panel under the dash — the cabin-side counterpart to the under-hood BJB. It distributes switched and unswitched power to the full suite of Town Car body electronics: LCM, instrument cluster, HVAC, wiper motor, DDM, DSM, PATS transceiver, ABS indicator feeds, restraints module, adjustable pedal switch, keypad assembly, electrochromatic mirror, decklid module, rear park aid, and both the driver and passenger seat heating modules. The Town Car's CJB has more active fuse positions than the Crown Vic equivalent — particularly the keypad entry, adjustable pedals (CJB #14), and DSM/DSM-adjacent circuits (CJB #19) — which reflect equipment that isn't present on non-luxury trim. CJB feeds come from BJB positions 103, 104, and 114, so a blown BJB maxi fuse will take out entire blocks of interior circuits that appear completely unrelated to each other. When diagnosing multi-system failures, trace the dead circuits back to their CJB fuse, then confirm the upstream BJB maxi fuse is intact before touching anything downstream.
Water intrusion is the primary CJB failure mode on all Panthers, and the Town Car is no exception — the cowl, windshield seal, and firewall grommets are the entry points to watch. Once water reaches the CJB or its connector pins, resistance climbs at the terminal faces, heat follows, and you start seeing blown fuses that come back, intermittent system behavior, or ghost codes in multiple modules. The two-step fix applies here exactly as with the BJB: find and eliminate the water source first, then inspect the CJB connector blocks and terminal faces for corrosion, heat distortion, or pin push-back. Green or black oxidation on the terminal face means resistance — cleaning it is a temporary measure. Terminals that have heated enough to show discoloration on the plastic need to be replaced, not cleaned, because the damage to the contact surface is permanent once it progresses that far.
| # | AMP | FUNCTION |
|---|---|---|
| 1 | 10A | Digital Transmission Range (DTR) sensor, starter relay |
| 2 | 10A | Restraints Control Module (RCM), Passenger Airbag Deactivation (PAD) indicator, Occupant Classification System Module (OCSM) |
| 3 | 10A | 2007: Audio, navigation control head; 2008–2011: Audio |
| 4 | 10A | 2007–2008: Back-up lamps; 2009–2011: Back-up lamps, Anti-lock Brake System (ABS) |
| 5 | 7.5A | Lighting Control Module (LCM) |
| 6 | 10A | Passive anti-theft transceiver module, ignition coils relay, PCM power diode, PCM power relay, fuel pump relay |
| 7 | 10A | Windshield wiper motor |
| 8 | 10A | 2007–2008: Power Deck-lid Module (PDM), overdrive cancel switch, cluster, compass module, LCM; 2009–2011: Power Deck-lid Module (PDM), overdrive cancel switch, cluster, compass module, LCM, traction control switch |
| 9 | 7.5A | 2007–2008: Mirror switch illumination, door lock switch illumination, heated seat switch illumination, electrochromatic mirror; 2009–2011: Door lock switch illumination, heated seat switch illumination, electrochromatic mirror |
| 10 | 15A | Multi-function switch (hazard lamps) |
| 11 | 15A | Multi-function switch (turn signal lamps) |
| 12 | 15A | Audio unit, audio/navigation control unit, navigation module |
| 13 | 10A | 2007–2008: Extended rear park aid module, Anti-lock Brake System (ABS), cluster; 2009–2011: Extended rear park aid module, cluster |
| 14 | 15A | Adjustable pedal switch, accessory delay relay |
| 15 | 10A | HVAC module |
| 16 | 20A | 2007–2008: Cigar lighter, OBD II (DLC); 2009–2011: OBD II (DLC) |
| 17 | 10A | A/C cycling switch, front heated seat module |
| 18 | 15A | Lighting Control Module (LCM) |
| 19 | 7.5A | Keypad switch assembly, exterior rear view mirror switch, Driver Door Module (DDM), Liftgate/Trunk Module (LTM), luggage compartment lid release switch, Driver Seat Module (DSM), seat adjust switch (driver front), door lock switch (driver and passenger), autolamp sensor |
| 20 | 10A | Lighting Control Module (LCM) |
| 21 | 10A | Clock, Lighting Control Module (LCM) |
| 22 | 10A | Lighting Control Module (LCM) |
| 23 | 10A | Lighting Control Module (LCM) |
| 24 | 15A | Lighting Control Module (LCM), multi-function switch (flash to pass) |
| 25 | 10A | Instrument Cluster (IC), HVAC module |
| 26 | 15A | Lighting Control Module (LCM) |
| 27 | — | Not used |
| 28 | 7.5A | Anti-lock Brake System (ABS) module, Lighting Control Module (LCM) |
| 29 | — | Not used |
| 30 | — | Not used |
| 31 | 5A | Lighting Control Module (LCM) |
| 32 | 7.5A | 2007: Delayed accessory — navigation, audio, moonroof; 2008–2011: Delayed accessory — audio |
| 33 | — | Not used |
| R | Relay | Accessory delay relay |
Legend
- # — Terminal Position
- ABS — Anti-lock Brake System
- ACC — Accessory
- AMP — Terminal Amperage
- DDM — Driver's Door Module
- DLC — Data Link Connector
- DRL — Daytime Running Lamps
- DSM — Driver Seat Module
- DTR — Digital Transmission Range
- EATC — Electronic Automatic Temperature Control
- FUNCTION — Circuit Function
- I/P — Instrument Panel
- LCM — Lighting Control Module
- LTM — Liftgate/Trunk Module
- MFS — Multi-Function Switch
- OCSM — Occupant Classification System Module
- PATS — Passive Anti-Theft System
- PCM — Powertrain Control Module
- PDM — Power Deck-lid Module
- R — Relay
- RCM — Restraints Control Module
- RASM — Rear Air Suspension Module
Trim Level Fuse Differences
The 2011 Town Car came in four trims: Executive, Signature, Signature Limited, and Signature L (the long-wheelbase stretch variant). The BJB and CJB physical boxes are shared across all trims, but some fuse positions are populated differently depending on equipment content. The biggest variable is the moonroof — standard on Executive and some Signature packages, deleting BJB #2's "moonroof" function from 2008 onward. The Signature L long-wheelbase adds rear HVAC and additional rear power points, which are fed through the standard circuit positions. If you're working on a car and the fuse diagram doesn't match what you're looking at, verify trim and option content before assuming a data error.
| Position | Executive / Signature | Signature Limited / Signature L |
|---|---|---|
| BJB #2 | 20A — Rear heated seats | 20A — Rear heated seats |
| BJB #15 | 15A — Lumbar, fuel door | 15A — Lumbar, fuel door |
| BJB #16 | 20A — Heated seats (front) | 20A — Heated seats (front) |
| BJB #108 | 40A — Power Deck-lid Module | 40A — Power Deck-lid Module |
| BJB #111 | 20A — Rear power point #1 | 20A — Rear power point #1 |
| BJB #113 | 20A — Rear power point #2 | 20A — Rear power point #2 |
| CJB #14 | 15A — Adjustable pedal switch (if equipped), accessory delay relay | 15A — Adjustable pedal switch, accessory delay relay |
| CJB #19 | 7.5A — DDM, DSM, keypad, mirror switch, door locks, autolamp | 7.5A — DDM, DSM, keypad, mirror switch, door locks, autolamp |
| BJB #117 | 20A — Cigar lighter (2009–2011); not used (2008) | 20A — Cigar lighter (2009–2011); not used (2008) |
Known Issues & TSB Reference
The items below cover documented issues for the 2011 Lincoln Town Car and the broader 2007–2011 Panther platform — either through Ford Technical Service Bulletins, extended warranty coverage, or well-established pattern failures. This is not a complete TSB list. Full TSB text is available through ALLDATA, Mitchell1, or your local Ford/Lincoln dealer service department.
Rear Air Suspension — Height Sensor, Compressor, and Air Spring Failures
Affected: 2003–2011 Lincoln Town Car. The air suspension system is the most failure-prone comfort system on the Town Car, and issues tend to compound — a failed height sensor triggers continuous compressor cycling, which kills the compressor, which eventually leads to a sagged rear end when the air springs can no longer hold pressure. The RASM module stores DTCs accessible via OBD-II. Common codes include C1715 (height sensor circuit fault), C1725 (rear suspension at full jounce), and C1726 (air spring solenoid circuit). Before replacing the compressor, confirm the air springs themselves aren't leaking — a compressor cycling every few minutes under normal driving conditions is almost always a leaking spring or fitting, not a failing motor. The compressor relay lives at BJB #302 (Mini Relay) and its feed fuse is BJB #112 (30A). If the compressor won't run at all, start there before condemning the unit. Reference: Ford TSB — Rear Air Suspension Diagnosis, 2003–2011 Town Car
Lighting Control Module (LCM) — Relay Solder Joint Failure
Affected: 2003–2011 Lincoln Town Car (and Ford Crown Victoria, Mercury Grand Marquis). The LCM relay develops a cracked solder joint at its board connection, causing intermittent or complete failure of headlamps, taillamps, and other LCM-controlled lighting circuits. On the Town Car the LCM sits behind the driver's kick panel. Symptoms include lights cutting out without warning, flickering, or a complete loss of exterior lighting with no blown fuse present. Ford issued extended warranty coverage specifically for this failure mode on early-production units. If your LCM is original and the relay solder joint is the failure point, the correct repair is a quality re-solder — not module replacement. Replacing the whole module with another used unit of unknown history just restarts the clock. Reference: Ford Extended Warranty Coverage — LCM Relay Solder Joint, 2003–2011 Panther Platform
4R75W — TCC Shudder / Harsh TCC Apply at Light Throttle
Affected: 2005–2011 Lincoln Town Car. Torque converter clutch shudder on light throttle application in the 35–55 mph range, or a harsh TCC apply in 2nd or 3rd gear, is a known pattern on the 4R75W in Town Car application. Root causes split two ways: fluid degradation (Mercon V breaks down under the Town Car's sustained highway load and livery duty cycles, allowing TCC slip and chatter), and PCM calibration mismatch (early-production 2005–2006 PCMs had a TCC lockup strategy that applied too early and too hard). For fluid-related cases, a fluid flush and refill with fresh Mercon V often resolves or significantly reduces the shudder. For PCM calibration issues, a reflash to the latest Ford calibration file is the documented fix. Don't confuse TCC shudder with engine misfire — both produce a similar vibration at cruise, but the TCC event is smooth-onset and speed/load-dependent, while misfire is typically rpm-dependent and sets a P030X code. Reference: Ford TSB — 4R75W TCC Shudder Diagnosis, 2005–2011 Town Car / Grand Marquis / Crown Victoria
Power Deck-lid Module (PDM) / Pulldown Motor — Inoperative or Slow Closure
Affected: 2003–2011 Lincoln Town Car. The power deck-lid system uses a pulldown module fed from BJB #116 (30A) and the PDM itself from BJB #108 (40A). If the deck lid won't latch automatically or closes slowly, the most common causes are a degraded pulldown motor, worn striker alignment, or a failed PDM. Less obvious is corrosion at the PDM connector — the PDM sits in the trunk area and is exposed to moisture from trunk seal failure or water migration around the rear window. Check the PDM connector pins for green/white oxidation before condemning the motor. A completely inoperative system with no DTCs stored and both BJB fuses intact usually points to a PDM ground issue or connector corrosion. Reference: Ford TSB — Power Deck-lid Module Inoperative, Lincoln Town Car
Electronic Throttle Control (ETC) — Wrench Light / Reduced Power Mode
Affected: 2005–2011 Lincoln Town Car. The ETC wrench light (reduced power mode) on Town Cars is triggered most often by APP sensor voltage mismatch at C175B (pins 4, 5, 6, 17, 24, 28) or throttle body contamination causing TPS1 and TPS2 (C175E pins 61 and 60) to fall out of their expected tracking ratio. The PCM monitors all three APP sensor signals simultaneously — if any two disagree by more than a calibrated threshold, the system enters limp mode. Before replacing the throttle body or APP sensor, clean the throttle bore and check C175B connector pins for pushed-back or corroded contacts. If the concern is intermittent, wiggle-test the connectors at C175B under load — intermittent wrench lights with no stored DTC are almost always a connector or terminal issue, not a failed sensor. Reference: Ford TSB — ETC Diagnostic Procedures, 2005–2011 Panther Platform ETC Vehicles
Scheduled Maintenance Intervals
The intervals below reflect Ford's Normal Schedule for the Town Car as published in the Scheduled Maintenance Guide covering 2007–2011 Panther platform vehicles. Normal schedule applies to typical everyday driving — not extended idling, livery or taxi service, or any heavy-use application. Town Cars in livery or taxi duty should follow the Special Operating Conditions schedule, which drops most fluid intervals significantly (oil to every 3,000 miles, ATF to every 30,000 miles). The air suspension system adds inspection intervals not present on Crown Vic or Grand Marquis — height sensor linkage, air spring condition, and compressor function should be checked at every major service interval, not just when a fault appears.
| Service Item | Normal Interval | Notes |
|---|---|---|
| Engine Oil & Filter | Every 5,000 miles or 6 months | SAE 5W-20 — 6 qts with filter. Livery/taxi: every 3,000 mi or 3 months |
| Tire Rotation | Every 5,000 miles | Inspect for uneven wear at each rotation — air suspension changes rear load behavior |
| Engine Air Filter | Every 30,000 miles | Motorcraft FA-1783 — replace sooner in dusty conditions |
| Fuel Filter | Every 30,000 miles | Motorcraft FG-986B — livery/high-use: every 15,000 miles |
| Spark Plugs | Every 100,000 miles | Motorcraft SP-413 — gapped at 0.054 in. Replace COP boots if cracked |
| PCV Valve | Every 100,000 miles | Replace at same interval as spark plugs |
| Serpentine Drive Belt | Inspect at 100,000 miles | Motorcraft JK6-926 — replace if cracked, glazed, or fraying |
| Engine Coolant | First change at 6 years or 100,000 miles | Motorcraft Premium Gold (yellow) — then every 3 years / 50,000 miles after |
| Automatic Transmission Fluid | Inspect at 15,000 mi intervals — change at 150,000 miles | Mercon V only. Livery/taxi: every 30,000 miles. Check condition, not just level |
| Brake Fluid | As needed / inspect annually | DOT 3 — replace if dark or boiling point has degraded |
| Brake System Inspection | Every 15,000 miles | Pads, rotors, lines, hoses, parking brake. Livery/taxi: every 5,000 miles |
| Rear Axle Lubricant | Inspect — synthetic fill considered "for life" | Livery/taxi: replace every 100,000 miles. Add Motorcraft XL-3 for Traction-Lok |
| Power Steering Fluid | Check at every oil change | Mercon ATF — ~2 pints capacity. Check condition and level |
| Air Suspension Inspection | Every 30,000 miles or at every major service | Inspect height sensor linkage, air spring condition, and compressor operation. Don't wait for a fault code |
| Cooling System Hoses | Inspect at every major service | Replace heater hose assembly at first sign of seeping — Motorcraft KH428 |
Other Lincoln Town Car Years
- 2003 Lincoln Town Car
- 2004 Lincoln Town Car
- 2005 Lincoln Town Car
- 2006 Lincoln Town Car
- 2007 Lincoln Town Car
- 2008 Lincoln Town Car
- 2009 Lincoln Town Car
- 2010 Lincoln Town Car
- 2011 Lincoln Town Car — You are here
Other Panther Platform Models
Data Disclaimer & Limitation of Liability
Read before using any data published on this site
Informational use only. All fuse assignments, relay positions, wire color codes, pin assignments, circuit numbers, connector identifiers, engine specifications, transmission specifications, torque values, maintenance intervals, and technical service bulletin references published on this site are provided for informational and reference purposes only. This data is not a substitute for a factory Ford, Lincoln, or Mercury service manual, an ALLDATA or Mitchell1 subscription, or the judgment of a qualified, licensed automotive technician.
No warranty. Data provided as-is. Riot Mind Studios, LLC makes no representations or warranties of any kind — express, implied, or statutory — regarding the completeness, accuracy, currency, or fitness for a particular purpose of any data published on this site. All information is provided strictly on an "as-is" and "as-available" basis. We do not warrant that any data point is free from error, omission, or misprint. We do not warrant that this data reflects the current production configuration of any specific vehicle.
Vehicle condition and prior modifications. The Panther Platform vehicles covered by this database (2003–2011 Ford Crown Victoria, Lincoln Town Car, Mercury Grand Marquis, and Mercury Marauder) are aging vehicles with decades of potential service history. Individual vehicles may have been subject to dealer modifications, police upfitter conversions, aftermarket electrical work, wiring repairs, fuse upgrades, or component substitutions that are not reflected in factory documentation or in the data published here. You are responsible for verifying all data against the actual condition of your specific vehicle before performing any repair, diagnostic test, or electrical work.
Model year and trim variation. Fuse assignments, relay types, PCM pin functions, and circuit configurations vary across model years, between trim levels (LX, P71/Police Interceptor, Executive, Signature, GS, LS, HPP, etc.), and in some cases between build dates within the same model year. Data that is accurate for one configuration may be incorrect or inapplicable for another. Always cross-reference this database against a source that is specific to your vehicle's model year, trim level, and build date.
Limitation of liability. To the fullest extent permitted by applicable law, Riot Mind Studios, LLC, its owner, affiliates, and any contributors shall not be liable for any direct, indirect, incidental, special, consequential, or punitive damages arising out of or related to your use of, or inability to use, any data, specification, schematic reference, or other content published on this site. This includes, without limitation: personal injury; vehicle damage; electrical damage; fire; failed emissions or safety inspections; failed diagnostic procedures; incorrect repairs; financial loss; towing costs; or damage to tools or property. Your use of this data is entirely at your own risk.
Professional consultation. Always consult a qualified technician before performing work on safety-critical systems including but not limited to: anti-lock brakes (ABS), supplemental restraint systems (SRS/airbags), fuel delivery, ignition, emissions-related components, and any circuit connected to the Powertrain Control Module (PCM). Incorrect wiring or fuse substitution on these systems can cause personal injury, fire, or permanent damage to vehicle electronics.
Affiliate links. Some links on this site are Amazon affiliate links. Riot Mind Studios, LLC earns a small commission on qualifying purchases at no additional cost to you. Affiliate links do not influence the data or technical content published on this site.
Third-party sources. Some data on this site is derived or cross-referenced from third-party sources including Ford Motor Company factory documentation, ALLDATA, and community-sourced vehicle databases. Riot Mind Studios, LLC does not represent Ford Motor Company, Lincoln, Mercury, or any affiliated brand in any capacity. All trademarks, model names, and manufacturer references are the property of their respective owners and are used here for identification purposes only.
