2010 Mercury Grand Marquis Info Systems & Data Sheets
The 2010 Mercury Grand Marquis runs the same 4.6L SOHC Romeo V8 and 4R75E four-speed automatic that carried the Panther platform through its final years. By 2010, the GS trim returned to the lineup after being dropped in 2009, so the model year technically offered both GS and LS variants — though the LS was primarily a fleet-channel car by this point and the GS was the de facto retail option. Both trim levels share the same drivetrain and electrical architecture. Engine output is 224 hp at 4,800 rpm and 275 lb-ft of torque, with a single exhaust setup — the 239 hp handling package that existed through 2007 was gone by 2008. Electronic throttle control (no cable, no IAC) has been standard on these since 2005, so idle and throttle-body behavior on the 2010 is entirely PCM-managed. The flex-fuel E85 capability introduced in 2007 carries over. What the 2010 Grand Marquis does not share with the Crown Victoria is the P71 police package — the Grand Marquis had no law enforcement variant, though it was used heavily in taxi and livery fleets, which puts its BJB and CJB failure modes in a different category than a grocery-run civilian car.
Download Your Schematics:
- 2010 Mercury Grand Marquis Battery Junction Fuse Box Schematic Data Sheet
- 2010 Mercury Grand Marquis Powertrain Control Module Schematic Data Sheet
- 2010 Mercury Grand Marquis Central Junction Box Schematic Data Sheet
Resources:
- Ford OBD-2 Diagnostic Trouble Codes List
- 2003 - 2011 Panther Platform Resources & Manuals List
- Label Installation Guide
Labels:
In this post:
- Battery Junction Box Fuse Panel Data & Info
- Powertrain Control Module Data & Info
- Central Junction Fuse Box Data & Info
- Engine Specifications
- Transmission Specifications
- Trim Level Fuse Differences
- Technical Service Bulletins & Known Issues
- Scheduled Maintenance Intervals
Engine Specifications
The 2010 Grand Marquis runs the 4.6L SOHC Romeo block — same cast-iron block, aluminum heads, and 2-valve-per-cylinder layout that's been in Panther platform cars since 1992. By 2010 it's fully drive-by-wire with no cable throttle and no idle air control valve. Output is 224 hp at 4,800 rpm, which has been the civilian Grand Marquis number since 2008 after the dual-exhaust handling package was dropped. Flex-fuel E85 capability is standard on the 2010.
| Specification | Value |
|---|---|
| Engine | 4.6L SOHC V8 (Romeo) |
| Displacement | 281 cu in (4,601 cc) |
| Block / Head Material | Cast iron block / aluminum heads |
| Bore × Stroke | 90.2 mm × 90.0 mm (3.55 in × 3.54 in) |
| Compression Ratio | 9.4:1 |
| Horsepower | 224 hp @ 4,800 rpm |
| Torque | 275 lb-ft @ 4,000 rpm |
| Valvetrain | SOHC, 2 valves per cylinder |
| Fuel System | Sequential multi-port EFI, flex-fuel (E85 capable) |
| Throttle Control | Electronic throttle control (ETC / drive-by-wire) |
| Engine Oil Capacity | 6 qts with filter |
| Oil Specification | SAE 5W-20 |
| Firing Order | 1-3-7-2-6-5-4-8 |
| Spark Plugs | Motorcraft SP-413 — gap 0.054 in |
Transmission Specifications
The 4R75E is a hydraulically controlled 4-speed automatic with electronic shift solenoids managed by the PCM. The "75" designation refers to the torque rating in lb-ft. By 2010, the 4R75E in the Grand Marquis incorporated the extended tail-shaft housing from the Crown Victoria, which was adopted starting with the 2010 model year. Fluid type is Mercon V — not Mercon, not Dexron. Using the wrong fluid causes shudder and premature clutch wear. The transmission pan holds approximately 11–12 qts for a full drain-and-fill with torque converter; a simple pan drop is around 5–6 qts.
| Specification | Value |
|---|---|
| Transmission | 4R75E 4-speed automatic |
| Gear Ratios — 1st | 2.84:1 |
| Gear Ratios — 2nd | 1.55:1 |
| Gear Ratios — 3rd | 1.00:1 |
| Gear Ratios — 4th (OD) | 0.70:1 |
| Reverse | 2.18:1 |
| Torque Converter | Hydraulic with electronic lockup (TCC) |
| Fluid Type | Mercon V ATF — do not substitute Mercon or Dexron |
| Pan Drain Capacity | ~5–6 qts (pan drop only) |
| Full Refill (with converter) | ~11–12 qts |
| Axle Ratio — Standard | 2.73:1 |
| Axle Ratio — Optional (Handling Pkg) | N/A — discontinued after 2007 |
| Shift Control | PCM-controlled solenoids (SSA, SSB, TCC via C175T) |
Battery Junction Box Fuse Panel Data & Info
Location: Engine bay, passenger side, behind battery | All information verified with AllData.
The Battery Junction Box (BJB) on 2003–2011 Panthers is the under-hood high-current fuse and relay distribution center — the first stop after the battery and alternator for power routing to the rest of the car. It carries the heavy loads and primary feeds: starter and charging distribution, PCM power, cooling fan, ABS, fuel pump relay circuits, and other major under-hood consumers depending on year and trim. It works in tandem with the interior Central Junction Box (CJB): the BJB handles the big power distribution and primary protection up front, while the CJB handles cabin-side branch circuits. That split matters for troubleshooting — if you have a widespread dead-car or charging complaint, you start at the battery cables, main feeds, and BJB before wasting time chasing interior fuses and modules. On the 2007–2011 Grand Marquis, relay positions 201–209 use 1/2 ISO relays and positions 301–304 use Full ISO relays — the same relay format as the Crown Victoria, not the Micro/Mini relay format used by the Town Car.
The most common BJB failures on fleet-duty Grand Marquis units are moisture and heat damage from high resistance — both usually trace back to the same root cause. Water gets into the box through poor sealing, cowl water paths, or repeated car washes; corrosion builds on fuse legs and bus contacts; resistance increases; heat follows. The symptoms are classic Panther electrical issues: intermittent no-crank, random power loss, repeated blown maxi fuses, charging problems, or multiple unrelated systems acting up at once. Taxi and fleet cars see this faster than low-mileage retail units because thermal cycling from constant use degrades the box seal and connections quicker. The fixes that hold: eliminate the water source and verify the BJB cover seal, pull and inspect fuses and relays for corrosion, and if you see melting, discoloration, or loose terminals, replace the affected terminals or the entire BJB. After repairs, confirm with a voltage-drop test across the main BJB feeds and grounds under load — high voltage drop means resistance is still present and the heat will return.
| # | AMP | Function |
|---|---|---|
| 1 | 30A | Ignition switch |
| 2 | 20A | 2007–2008: Moon roof; 2009–2011: Not used |
| 3 | 10A | Powertrain control module (PCM) – keep alive power, Canister vent |
| 4 | 20A | Fuel relay feed |
| 5 | 10A | Rear Air Suspension Module (RASM); 2007–2008: VASM |
| 6 | 15A | Alternator regulator |
| 7 | 30A | PCM relay feed |
| 8 | 20A | Driver's Door Module (DDM), Door locks (2007–2008) |
| 9 | 15A | Ignition coil relay feed |
| 10 | 20A | Horn relay feed |
| 11 | 15A | A/C clutch relay feed |
| 12 | 20A | Audio (subwoofer) |
| 13 | 20A | Instrument panel power point |
| 14 | 20A | Stop lamp switch |
| 15 | 15A | Fog lamps |
| 16 | 20A | Heated seats |
| 17 | — | Not used |
| 18 | — | Not used |
| 19 | 15A | Powertrain Control Module (PCM), Fuel injectors |
| 20 | 15A | PCM |
| 21 | 15A | Powertrain loads and sensors |
| 22 | — | Not used |
| 23 | — | Not used |
| 24 | 10A | Heated mirror, Rear defrost indicator |
| 101 | 40A | Blower relay feed |
| 102 | 50A | Cooling fan |
| 103 | 50A | Instrument panel (I/P) fuse box feed #1 — I/P fuses 10, 12, 14, 16, and 18 |
| 104 | 50A | Instrument panel (I/P) fuse box feed #2 — I/P fuses 2, 4, 6, 8, 19, 21, 23, and 25 |
| 105 | 30A | Starter relay feed |
| 106 | 40A | Anti-lock Brake System (ABS) module (pump) |
| 107 | 40A | Rear defroster relay feed |
| 108 | 20A | 2007–2008: Not used; 2009–2011: Cigar lighter |
| 109 | 20A | ABS module (valves) |
| 110 | 30A | Wiper module |
| 111 | — | Not used |
| 112 | 30A | Air suspension compressor |
| 113 | — | Not used |
| 114 | — | Not used |
| 115 | — | Not used |
| 116 | — | Not used |
| 117 | — | Not used |
| 118 | — | Not used |
| 201 | 1/2 ISO | A/C clutch |
| 202 | — | Not used |
| 203 | 1/2 ISO | Ignition coil |
| 204 | 1/2 ISO | Powertrain Control Module (PCM) |
| 205 | 1/2 ISO | Fog lamps |
| 206 | 1/2 ISO | Fuel |
| 207 | — | Not used |
| 208 | — | Not used |
| 209 | 1/2 ISO | Horn |
| 301 | Full ISO | Starter |
| 302 | Full ISO | Air compressor (air suspension) |
| 303 | Full ISO | Blower |
| 304 | Full ISO | Rear defrost |
| 401 | — | Not used |
| 501 | Diode | 2007–2008: A/C clutch; 2009–2011: Not used |
| 502 | Diode | Powertrain Control Module (PCM) |
| 503 | 20A Circuit Breaker | 2007: Horn, Door latch; 2008–2011: Not used |
| 601 | 20A Circuit Breaker | Power seats, Lumbar, Deck lid |
| 602 | 20A Circuit Breaker | Power windows relay feed (RUN/ACC) |
Legend
- # — Terminal position
- ABS — Anti-lock Brake System
- ACC — Accessory
- AMP — Terminal amperage
- DDM — Driver's Door Module
- EATC — Electronic Automatic Temperature Control
- Function — Circuit function
- I/P — Instrument panel
- ISO — International Standards Organization
- LCM — Lighting Control Module
- PCM — Powertrain Control Module (also: Electronic Control Unit)
- RASM — Rear Air Suspension Module
- VASM — Variable Assist Steering Module
Powertrain Control Module (PCM/ECU) Data & Info
Location: Engine bay, driver side inner fender | All information verified with AllData.
The PCM on the 2010 Grand Marquis is a 3-connector, 170-pin unit mounted on the driver side inner fender. It manages fuel delivery, ignition timing, transmission shift commands, ETC throttle control, emissions, and PATS immobilization. The three connectors are C175T (left, black housing, 12B637), C175B (center, black housing, 14290), and C175E (right, black housing, 12B637). The 2007+ connector layout differs significantly from 2005–2006 — the injector outputs moved from C175E to pins within the center and right connectors, and the COP controls consolidated on C175E. The 2010 PCM does not have the SCP bus pins (C175T pins 35–36) that appeared on 2005 units, and several pins used for analog cluster signals in earlier years are unused by 2010.
C175B pin 8 on the 2010 Grand Marquis is the traction control switch on/off signal (GY, circuit 959) — this differs from the Crown Victoria where pin 8 carries brake pedal position switch data in some years. C175T pin 21 is not used on the 2010 Grand Marquis — this pin carried the engine vacuum signal on the 2005 Grand Marquis and differs from the Town Car where it carries an ETC warning indicator control. Before condemning a PCM on a 2010, verify all three connector boots are seated properly with no corrosion on the C175T or C175B ground cluster. C175B pins 47–50 are all BK/WH, circuit 570, 18-gauge ground — a high resistance reading across any of these under load points to a ground strap issue at the PCM bracket, not a failed module.
Diagnosing PCM-related issues on the 2010 requires a scan tool with live PID access and a digital multimeter. Confirm 5V reference at sensor signal wires before condemning sensors — the PCM supplies 5V to the MAF, MAP, TPS, DPFE, and pedal position sensors. A missing 5V reference usually means a wiring fault or a shorted sensor pulling the reference line down, not a failed PCM. Voltage drop across the C175B ground cluster under load should be 0.2V or less. Anything higher and you have a ground path problem that will produce random codes and erratic sensor data. If the PCM needs replacement, it requires programming via Ford IDS or a J2534 pass-through device, and PATS must be re-initialized to accept the replacement module.
C175T (BK) | LEFT (12B637)
| Pin | Color | Circuit | Gauge | Function |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | DB/YE | 136 | 20 | Output shaft speed (OSS) sensor signal |
| 4 | — | — | — | Not used |
| 5 | — | — | — | Not used |
| 6 | — | — | — | Not used |
| 7 | — | — | — | Not used |
| 8 | — | — | — | Not used |
| 9 | — | — | — | Not used |
| 10 | — | — | — | Not used |
| 11 | WH/YE | 925 | 20 | Electronic pressure control (EPC) solenoid |
| 12 | — | — | — | Not used |
| 13 | — | — | — | Not used |
| 14 | — | — | — | Not used |
| 15 | DG/WH | 970 | 20 | Turbine shaft speed (TSS) sensor signal |
| 16 | YE/BK | 1144 | 20 | Digital transmission range (DTR) sensor, TR1 |
| 17 | LB/BK | 1145 | 20 | Digital transmission range (DTR) sensor, TR2 |
| 18 | — | — | — | Not used |
| 19 | — | — | — | Not used |
| 20 | — | — | — | Not used |
| 21 | — | — | — | Not used |
| 22 | — | — | — | Not used |
| 23 | — | — | — | Not used |
| 24 | RD/LG | 392 | 18 | Heated oxygen sensor (HO2S) #12 input |
| 25 | VT/LG | 393 | 18 | Heated oxygen sensor (HO2S) #22 input |
| 26 | — | — | — | Not used |
| 27 | RD/BK | 1268 | 20 | Digital transmission range (DTR) sensor, TR3A |
| 28 | WH/BK | 1143 | 20 | Digital transmission range (DTR) sensor, TR4 |
| 29 | OG/BK | 923 | 20 | Transmission fluid temperature (TFT) sensor |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | OG/RD | 1269 | 20 | Anti-theft indicator control |
| 33 | — | — | — | Not used |
| 34 | — | — | — | Not used |
| 35 | — | — | — | Not used |
| 36 | — | — | — | Not used |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | OG/YE | 237 | 20 | Shift solenoid A |
| 43 | VT/OG | 315 | 20 | Shift solenoid B |
| 44 | — | — | — | Not used |
| 45 | — | — | — | Not used |
| 46 | VT/YE | 126 | 20 | Torque converter clutch (TCC) solenoid |
| 47 | WH/BK | 389 | 18 | Heated oxygen sensor (HO2S) #12 heater |
| 48 | TN/YE | 390 | 18 | Heated oxygen sensor (HO2S) #22 heater return |
| 49 | — | — | — | Not used |
| 50 | — | — | — | Not used |
C175B (BK) | CENTER (14290)
| Pin | Color | Circuit | Gauge | Function |
|---|---|---|---|---|
| 1 | GY/BK | 679 | 18 | Vehicle speed signal |
| 2 | GY/RD | 3405 | 20 | Starter relay control |
| 3 | RD/PK | 791 | 20 | Fuel tank pressure transducer sensor signal |
| 4 | WH/LB | 3093 | 20 | APP, Vref 2 |
| 5 | TN/YE | 1283 | 20 | Accelerator pedal position signal |
| 6 | TN/WH | 1284 | 20 | APP return 2 |
| 7 | — | — | — | Not used |
| 8 | GY | 959 | 20 | Traction control switch on/off signal |
| 9 | OG | 636 | 18 | Brake pedal position signal |
| 10 | BK | 57 | 18 | Ground |
| 11 | WH/LG | 1827 | 20 | HS CAN+ |
| 12 | LB/OG | 926 | 20 | Modulated fuel pump signal |
| 13 | VT/WT | 91 | 20 | EVAP canister vent control solenoid control |
| 14 | OG/LB | 73 | 20 | A/C clutch relay control |
| 15 | PK/LB | 883 | 20 | A/C cycling switch signal |
| 16 | — | — | — | Not used |
| 17 | WH | 3012 | 20 | Accelerator pedal position 2 signal |
| 18 | — | — | — | Not used |
| 19 | LB/BK | 151 | 20 | Speed control switch reference voltage |
| 20 | YE/BK | 1799 | 20 | RDI / VEMS signal |
| 21 | DG/YE | 238 | 20 | Fuel pump monitor |
| 22 | — | — | — | Not used |
| 23 | PK/LG | 1828 | 20 | HS CAN- |
| 24 | LB/BK | 3091 | 20 | APP, Vref |
| 25 | — | — | — | Not used |
| 26 | WH/BK | 1154 | 20 | A/C pressure transducer sensor signal |
| 27 | — | — | — | Not used |
| 28 | WH/RD | 3015 | 20 | Accelerator pedal position 3 signal |
| 29 | TN/WH | 224 | 20 | Transmission control switch signal |
| 30 | DG/OG | 848 | 20 | Speed control switch, signal return |
| 31 | WH/LG | 1215 | 20 | TX signal |
| 32 | YE/LB | 1816 | 20 | Generator communication |
| 33 | — | — | — | Not used |
| 34 | YE/LG | 330 | 20 | Power steering pressure switch signal |
| 35 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 36 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | BR/WH | 351 | 20 | Reference voltage |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | GY/OG | 1216 | 20 | RX signal |
| 43 | — | — | — | Not used |
| 44 | VT | 107 | 20 | Flash / EEPROM power supply |
| 45 | RD/WH | 729 | 20 | Voltage supplied at all times (overload protected) |
| 46 | — | — | — | Not used |
| 47 | BK/WH | 570 | 18 | Ground |
| 48 | BK/WH | 570 | 18 | Ground |
| 49 | BK/WH | 570 | 18 | Ground |
| 50 | BK/WH | 570 | 18 | Ground |
C175E (BK) | RIGHT (12B637)
| Pin | Color | Circuit | Gauge | Function |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | WH/OG | 369 | 20 | Heated PTC control |
| 4 | — | — | — | Not used |
| 5 | YE | 1817 | 20 | Generator monitor control |
| 6 | LB/BK | 191 | 20 | Vapor management valve control |
| 7 | RD/OG | 229 | 20 | Engine cooling fan motor control |
| 8 | — | — | — | Not used |
| 9 | WH/RD | 1029 | 20 | Coil on plug (COP) 8 control |
| 10 | LG/YE | 1021 | 20 | Coil on plug (COP) 5 control |
| 11 | PK/WH | 1026 | 20 | Coil on plug (COP) 2 control |
| 12 | WH/PK | 1028 | 20 | Coil on plug (COP) 3 control |
| 13 | — | — | — | Not used |
| 14 | DG/VT | 1030 | 20 | Coil on plug (COP) 4 control |
| 15 | OG/YE | 1025 | 20 | Coil on plug (COP) 6 control |
| 16 | PK/LB | 1027 | 20 | Coil on plug (COP) 7 control |
| 17 | LG/WH | 1024 | 20 | Coil on plug (COP) 1 control |
| 18 | — | — | — | Not used |
| 19 | LB | 1164 | 20 | Injector temperature sensor signal |
| 20 | — | — | — | Not used |
| 21 | BR/LG | 352 | 20 | Differential pressure feedback EGR (DPFE) sensor input |
| 22 | GY | 743 | 20 | Intake air temperature (IAT) sensor signal |
| 23 | — | — | — | Not used |
| 24 | — | — | — | Not used |
| 25 | LB/RD | 967 | 20 | Mass air flow (MAF) sensor signal |
| 26 | TN/LB | 968 | 20 | Mass air flow (MAF) sensor signal return |
| 27 | — | — | — | Not used |
| 28 | GY/LB | 74 | 18 | Heated oxygen sensor (HO2S) #11 input |
| 29 | RD/BK | 94 | 18 | Heated oxygen sensor (HO2S) #21 input |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | RD/PK | 141 | 20 | Injector pressure sensor signal |
| 33 | — | — | — | Not used |
| 34 | DB/YE | 1835 | 20 | Electronic throttle control motor + |
| 35 | WH | 556 | 20 | Fuel injector 2 control |
| 36 | BR/LB | 558 | 20 | Fuel injector 4 control |
| 37 | LG/OG | 560 | 20 | Fuel injector 6 control |
| 38 | LB | 562 | 20 | Fuel injector 8 control |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | YE/LG | 1102 | 20 | Cylinder head temperature sensor signal |
| 42 | — | — | — | Not used |
| 43 | — | — | — | Not used |
| 44 | — | — | — | Not used |
| 45 | DB/OG | 282 | 20 | Camshaft position sensor signal |
| 46 | GY/YE | 139 | 20 | Crankshaft position sensor — |
| 47 | BK/PK | 138 | 20 | Crankshaft position sensor + |
| 48 | YE | 1273 | 20 | Knock sensor — |
| 49 | YE/RD | 310 | 20 | Knock sensor + |
| 50 | — | — | — | Not used |
| 51 | OG/YE | 1836 | 20 | Electronic throttle control motor — |
| 52 | TN | 555 | 20 | Fuel injector 1 control |
| 53 | BR/YE | 557 | 20 | Fuel injector 3 control |
| 54 | TN/BK | 559 | 20 | Fuel injector 5 control |
| 55 | TN/RD | 561 | 20 | Fuel injector 7 control |
| 56 | — | — | — | Not used |
| 57 | BR/WH | 351 | 20 | Reference voltage |
| 58 | GY/RD | 359 | 20 | Signal return |
| 59 | PK/OG | 1858 | 20 | Electronic throttle control module signal return |
| 60 | YE/WH | 357 | 20 | Throttle position (TPS) sensor signal 2 |
| 61 | GY/WH | 355 | 20 | Throttle position (TPS) sensor signal 1 |
| 62 | LB/RD | 3067 | 20 | Manifold absolute pressure (MAP) sensor input |
| 63 | BR/PK | 360 | 20 | EGR vacuum regulator signal |
| 64 | — | — | — | Not used |
| 65 | — | — | — | Not used |
| 66 | YE/WH | 1857 | 20 | Electronic throttle control module reference voltage |
| 67 | — | — | — | Not used |
| 68 | — | — | — | Not used |
| 69 | RD/WH | 387 | 18 | Heated oxygen sensor (HO2S) #11 heater |
| 70 | YE/LB | 388 | 18 | Heated oxygen sensor (HO2S) #21 heater |
Wire Color Legend
- BK — Black
- BR — Brown
- DB — Dark Blue
- DG — Dark Green
- GY — Gray
- LB — Light Blue
- LG — Light Green
- OG — Orange
- PK — Pink
- RD — Red
- TN — Tan
- VT — Violet
- WH — White
- YE — Yellow
Central Junction Fuse Box Data & Info
Location: Driver side compartment, under steering wheel | All information verified with AllData.
The Central Junction Box (CJB) on 2003–2011 Panther-platform cars is the interior fuse and relay panel under the dash that distributes power and signals to the body and chassis electronics — lighting, wipers, HVAC, power windows and locks, key-in and ignition logic, and more. Think of it as the cabin-side power traffic controller, separate from the under-hood Battery Junction Box. Ford labels interior fuses as F2.xx (CJB) and under-hood as F1.xx (BJB), which matters when diagnosing because chasing the wrong box wastes time. The CJB is also the constant reference point in factory diagnostic steps for "fused ignition voltage" to multiple modules because it is exactly that — the distribution hub for switched power to a significant portion of the car's electronics. On the 2010 Grand Marquis specifically, fuse 33 for the Fire Suppression System Module applies to fleet-equipped vehicles only and will be unused on standard retail cars.
The most common real-world CJB problem on Panthers is water intrusion and corrosion, not the box failing on its own. When cowl drains, windshield seals, or firewall pass-throughs allow water behind the dash, it can drip near the CJB area and soak the harness and connectors. Once moisture gets into terminals, the result is the classic Panther electrical gremlin pattern: intermittent no-start, erratic lighting, wipers operating independently, random fuse failures, or multiple unrelated circuits acting up simultaneously. Taxi and livery fleet Grand Marquis units see accelerated CJB issues due to the constant thermal cycling and higher annual mileage. The fix is two steps: eliminate the leak at the source first, then inspect the CJB and its connectors for corrosion and overheated terminals. Contact cleaner alone will not fix corroded terminals — if pins show green or black oxidation or if plastic shows heat distortion, repair or replace the terminals.
| # | AMP | Function |
|---|---|---|
| 1 | 10A | Ignition (START) — Starter relay coil, Digital Transmission Range (DTR) sensor |
| 2 | 7.5A | 2007–2011: Power mirrors, Door lock switches (2007–2008), Mirror switch, Keypad switch, Decklid switch, Adjustable pedal switch, Driver's Door Module, Cluster |
| 3 | 5A | Audio Control Module (ACM) |
| 4 | 10A | Autolamp sensor, Lighting Control Module (LCM) |
| 5 | 7.5A | Lighting Control Module (LCM) |
| 6 | 7.5A | Lighting Control Module (LCM) |
| 7 | 10A | Windshield wiper motor |
| 8 | 10A | Electronic Automatic Temperature Control (EATC) module (vehicles equipped with EATC only) |
| 9 | 7.5A | 2007–2011: Ignition (ON/ACC) — Door lock switch illumination, Heated seat switch illumination, Moon roof (2007–2008), Overhead console, Radio, Antenna, Electrochromatic mirror, Window relay coil |
| 10 | 15A | Multi-function switch — Hazards |
| 11 | 15A | Multi-function switch — Turn signals |
| 12 | 15A | Audio Control Module (ACM) |
| 13 | 10A | 2007–2011: Ignition (ON) — Anti-lock Brake System (ABS) module (2007–2008), Rear Air Suspension Module (RASM), Variable Assist Power Steering (VAPS) (2007–2008), Cluster |
| 14 | 15A | Taxi roof lamp switch, Adjustable pedal switch |
| 15 | 10A | Climate control assembly, HVAC module, EATC, Blower motor relay |
| 16 | 20A | 2007–2008: Cigar lighter, On-board diagnostics (OBD-II); 2009–2011: On-board diagnostics (OBD-II) |
| 17 | 10A | Temperature blend door actuator, Climate control assembly, Heated seat module driver side front, Heated seat module passenger side front, Brake shift interlock |
| 18 | 15A | Lighting Control Module (LCM) — Interior lighting |
| 19 | 10A | Lighting Control Module (LCM) — Left-hand low beam |
| 20 | 10A | Digital Transmission Range (DTR) sensor, Ignition (ON/ACC) — Back-up lamps, Anti-lock Brake System (ABS) (2009–2011) |
| 21 | 10A | Lighting Control Module (LCM) — Right-hand low beam |
| 22 | 10A | Passenger Air Bag Deactivation (PAD) indicator, Restraints Control Module (RCM), Occupant Classification System Module (OCSM) |
| 23 | 15A | Multi-function switch (flash-to-pass), Lighting Control Module (LCM) — High beams |
| 24 | 10A | Ignition (ON/ACC) — Passive Anti-Theft System (PATS) module, PCM relay coil, Fuel relay coil, Ignition coil relay coil |
| 25 | 15A | Lighting Control Module (LCM) — Park lamps, corner lamps, license lamps |
| 26 | 10A | Ignition (ON/START) — Cluster, Lighting Control Module, Overdrive cancel switch, Rear defroster relay coil (2006), Traction control switch (2009–2011) |
| 27 | — | Not used |
| 28 | 7.5A | Lighting Control Module (LCM), Brake shift interlock, Anti-lock Brake System (ABS) module |
| 29 | — | Not used |
| 30 | — | Not used |
| 31 | 5A | Lighting Control Module (LCM) — Key in |
| 32 | — | Not used |
| 33 | 10A | Fire Suppression System Module (FSSM), Fire suppression manual switch — If equipped |
| R | Relay | Accessory delay relay |
Legend
- # — Terminal position
- ABS — Anti-lock Brake System
- ACC — Accessory
- AMP — Terminal amperage
- DDM — Driver's Door Module
- DRL — Daytime Running Lamps
- DTR — Digital Transmission Range
- EATC — Electronic Automatic Temperature Control
- Function — Circuit function
- I/P — Instrument panel
- ISO — International Standards Organization
- LCM — Lighting Control Module
- MFS — Multi-Function Switch
- PCM — Powertrain Control Module
- R — Relay
- RASM — Rear Air Suspension Module
Trim Level Fuse Differences
| Position | GS | LS Fleet |
|---|---|---|
| CJB Fuse 8 (10A) | HVAC module / manual climate | EATC module (if equipped) |
| CJB Fuse 14 (15A) | Adjustable pedal switch | Adjustable pedal switch |
| CJB Fuse 33 (10A) | Not used on standard retail units | Fire Suppression System Module (if fleet-equipped) |
| BJB Fuse 15 (15A) | Fog lamps (if equipped) | Fog lamps (if equipped) |
| BJB Fuse 16 (20A) | Heated seats (if equipped) | Heated seats (standard) |
| BJB Position 108 (20A) | 2009–2011: Cigar lighter | 2009–2011: Cigar lighter |
Technical Service Bulletins & Known Issues
The TSBs below cover documented issues relevant to the 2010 Mercury Grand Marquis. Full bulletin text is available through ALLDATA, Mitchell1, or your dealership. Platform-wide TSBs that apply to Crown Victoria and Town Car of the same era are noted where applicable — the 4R75E transmission issues in particular apply across all three Panther models. Verify applicability by VIN and build date before acting on any TSB.
4R75E Transmission — Grinding, Whine, Vibration, or Gear Slippage
Affected: 2009–2011 Mercury Grand Marquis (and other Ford/Mercury/Lincoln vehicles with 4R75E). A service kit was released to address proper repair of 4R75E units exhibiting grinding noise, whine, vibration, gear slippage, or loss of reverse. The root cause is failure of the planetary gear assembly. If a 2010 Grand Marquis is showing any of these symptoms — particularly intermittent loss of reverse or slippage accompanied by metallic debris in the fluid — drain and inspect the pan before driving further. Metal contamination means the transmission needs to come apart, not a fluid change.Reference: TSB 16-0032 / TSB 14-0153 — 4R75E Planetary Gear Assembly Failure, Multiple Ford/Mercury/Lincoln applications
Intermediate Steering Shaft — Corrosion and Loss of Steering Control
Affected: 2005–2011 Crown Victoria and Grand Marquis (Regional Program 13R01 / Safety Recall 13S08). Corrosion of the swing link joints on the lower intermediate steering shaft, combined with a collapsed upper intermediate steering shaft, can result in steering column separation and loss of steering control. This is a safety-critical issue. Vehicles in high-corrosion states were included in Safety Recall 13S08; vehicles not in corrosion states but showing the condition fall under Regional Program 13R01. Any 2010 Grand Marquis with high mileage in a salt-belt state should have the intermediate steering shaft inspected and replaced if corrosion is present at the swing links.Reference: RP-13R01 / Safety Recall 13S08 — Intermediate Steering Shaft Corrosion, 2005–2011 Grand Marquis / Crown Victoria
Right Rear Axle — Oil Leak at Wheel Bearing Seal
Affected: 2009–2011 Mercury Grand Marquis (and other Panther platform vehicles). Oil leaks from the right rear axle wheel bearing oil seal may be caused by a combination of a damaged seal and poor surface finish on the axle shaft itself. Replacing the seal alone without addressing the axle shaft surface finish will result in the leak returning. Inspect the axle shaft for scoring or rough finish in the seal contact area before reinstalling or replacing. On high-mileage fleet units, check both sides — the left axle is less common but not immune.Reference: TSB 09-3-1 — Right Rear Axle Oil Leak, Panther Platform vehicles
ETC / Drive-by-Wire — Throttle Body Carbon Buildup and Idle Quality
Affected: 2007–2011 Mercury Grand Marquis. Without a cable-operated throttle or idle air control valve, carbon buildup on the throttle bore and plate is the primary cause of rough idle, idle surging, and hesitation at light throttle on the 2010. The PCM manages idle entirely through the electronic throttle motor, so a dirty throttle body creates a calibration mismatch between the pedal position sensors and actual airflow. Clean the throttle bore with dedicated throttle body cleaner (not carb cleaner) and perform a throttle body re-learn procedure after cleaning. Do not use abrasive pads on the bore coating. If idle complaints persist after cleaning, check TPS1 (C175E pin 61) and TPS2 (C175E pin 60) for proper tracking — they should be inverse of each other through the sweep with no dropout.Reference: Platform-wide known issue — ETC Throttle Body Carbon Buildup, 2007–2011 Grand Marquis
COP Ignition Boots — Misfire and Carbon Tracking
Affected: 2007–2011 Mercury Grand Marquis. The 2010 uses 8 individual DG-508 coil-on-plug units with no distributor. Common failure mode is cracked or carbon-tracked boots — particularly at the valley-position cylinders that run hotter and retain more heat. A single bad COP boot can produce P030X misfire codes, and if sustained, the voltage spike can backfeed into the PCM through the C175E connector. Always inspect boots and plug condition together when diagnosing a misfire. COP outputs on the 2010 are on C175E pins 9–12 and 14–17. Replace plugs (SP-413, gap 0.054 in) whenever replacing COP boots on a high-mileage unit.Reference: Known issue — COP Boot Failure / Carbon Tracking, 2007–2011 Grand Marquis 4.6L SOHC
Scheduled Maintenance Intervals
The intervals below reflect Ford's Normal Schedule as published in the Scheduled Maintenance Guide covering the Grand Marquis, Crown Victoria, and Town Car. Normal schedule applies to typical everyday driving. If the vehicle has seen taxi duty, livery use, extended idling, or towing, the Special Operating Conditions schedule applies — most fluid intervals drop significantly under that schedule (oil every 3,000 miles or 3 months, ATF every 30,000 miles). The 2010 Grand Marquis saw heavy fleet use as a taxi and car service vehicle, so many surviving examples belong on the heavy-use schedule regardless of what the odometer shows.
| Service Item | Normal Interval | Notes |
|---|---|---|
| Engine Oil & Filter | Every 5,000 miles or 6 months | SAE 5W-20 — 6 qts with filter. Taxi/livery/heavy use: every 3,000 mi or 3 months |
| Tire Rotation | Every 5,000 miles | Inspect for wear and pressure at each rotation |
| Engine Air Filter | Every 30,000 miles | Motorcraft FA-1783 — replace sooner in dusty conditions |
| Fuel Filter | Every 30,000 miles | Heavy use / taxi: every 15,000 miles |
| Spark Plugs | Every 100,000 miles | Motorcraft SP-413 — gapped at 0.054 in. Inspect COP boots at same time |
| PCV Valve | Every 100,000 miles | Replace at same interval as plugs |
| Serpentine Drive Belt | Inspect at 100,000 miles | Replace if cracked, glazed, or fraying |
| Engine Coolant | First change at 6 years or 100,000 miles | Motorcraft Premium Gold (yellow) — then every 3 years or 50,000 miles after first change |
| Automatic Transmission Fluid | Inspect at 15,000 mi intervals — change at 150,000 miles | Mercon V only. Taxi/heavy use: every 30,000 miles. Check condition and level, not just level |
| Brake Fluid | As needed — inspect annually | DOT 3 — replace if fluid is dark or boiling point has degraded |
| Brake System Inspection | Every 15,000 miles | Pads, rotors, lines, hoses, parking brake. Taxi/fleet: every 5,000 miles |
| Rear Axle Lubricant | Inspect — synthetic fill considered "for life" | Taxi/fleet: replace every 100,000 miles. 80W-90 standard or 75W-140 synthetic. Add XL-3 friction modifier for Traction-Lok axle |
| Power Steering Fluid | Check at every oil change | Mercon ATF — approximately 2 pints capacity |
| Cooling System Hoses | Inspect at every major service | Replace heater hose assembly at first sign of seeping |
Other Mercury Grand Marquis Years
Other Panther Platform Models
Data Disclaimer & Limitation of Liability
Read before using any data published on this site
Informational use only. All fuse assignments, relay positions, wire color codes, pin assignments, circuit numbers, connector identifiers, engine specifications, transmission specifications, torque values, maintenance intervals, and technical service bulletin references published on this site are provided for informational and reference purposes only. This data is not a substitute for a factory Ford, Lincoln, or Mercury service manual, an ALLDATA or Mitchell1 subscription, or the judgment of a qualified, licensed automotive technician.
No warranty. Data provided as-is. Riot Mind Studios, LLC makes no representations or warranties of any kind — express, implied, or statutory — regarding the completeness, accuracy, currency, or fitness for a particular purpose of any data published on this site. All information is provided strictly on an "as-is" and "as-available" basis. We do not warrant that any data point is free from error, omission, or misprint. We do not warrant that this data reflects the current production configuration of any specific vehicle.
Vehicle condition and prior modifications. The Panther Platform vehicles covered by this database (2003–2011 Ford Crown Victoria, Lincoln Town Car, Mercury Grand Marquis, and Mercury Marauder) are aging vehicles with decades of potential service history. Individual vehicles may have been subject to dealer modifications, police upfitter conversions, aftermarket electrical work, wiring repairs, fuse upgrades, or component substitutions that are not reflected in factory documentation or in the data published here. You are responsible for verifying all data against the actual condition of your specific vehicle before performing any repair, diagnostic test, or electrical work.
Model year and trim variation. Fuse assignments, relay types, PCM pin functions, and circuit configurations vary across model years, between trim levels (LX, P71/Police Interceptor, Executive, Signature, GS, LS, HPP, etc.), and in some cases between build dates within the same model year. Data that is accurate for one configuration may be incorrect or inapplicable for another. Always cross-reference this database against a source that is specific to your vehicle's model year, trim level, and build date.
Limitation of liability. To the fullest extent permitted by applicable law, Riot Mind Studios, LLC, its owner, affiliates, and any contributors shall not be liable for any direct, indirect, incidental, special, consequential, or punitive damages arising out of or related to your use of, or inability to use, any data, specification, schematic reference, or other content published on this site. This includes, without limitation: personal injury; vehicle damage; electrical damage; fire; failed emissions or safety inspections; failed diagnostic procedures; incorrect repairs; financial loss; towing costs; or damage to tools or property. Your use of this data is entirely at your own risk.
Professional consultation. Always consult a qualified technician before performing work on safety-critical systems including but not limited to: anti-lock brakes (ABS), supplemental restraint systems (SRS/airbags), fuel delivery, ignition, emissions-related components, and any circuit connected to the Powertrain Control Module (PCM). Incorrect wiring or fuse substitution on these systems can cause personal injury, fire, or permanent damage to vehicle electronics.
Affiliate links. Some links on this site are Amazon affiliate links. Riot Mind Studios, LLC earns a small commission on qualifying purchases at no additional cost to you. Affiliate links do not influence the data or technical content published on this site.
Third-party sources. Some data on this site is derived or cross-referenced from third-party sources including Ford Motor Company factory documentation, ALLDATA, and community-sourced vehicle databases. Riot Mind Studios, LLC does not represent Ford Motor Company, Lincoln, Mercury, or any affiliated brand in any capacity. All trademarks, model names, and manufacturer references are the property of their respective owners and are used here for identification purposes only.
