2009 Mercury Grand Marquis Info Systems & Data Sheets
The 2009 Mercury Grand Marquis runs Ford's 4.6L 2-valve SOHC "Romeo" V8 — 224 hp at 4,800 rpm, 272 lb-ft at 4,000 rpm, 9.4:1 compression, backed by the 4R75E 4-speed automatic. By 2009 the platform had been in this configuration for four years, since Electronic Throttle Control (ETC) arrived for the 2005 model year. The 2009 is mid-run Panther: no major architecture changes from 2007–2008, but the electrical system reflects several position-level differences from those earlier years worth knowing about. BJB position 2 drops the moonroof circuit (gone after 2008), position 108 picks up the cigar lighter (relocated from the CJB in 2007–2008), and the A/C clutch diode at BJB 501 is no longer populated. On the CJB side, position 16 drops the cigar lighter (that circuit moved to the BJB) and position 20 picks up ABS module coverage that was previously elsewhere. The Grand Marquis was sold in GS, GS Convenience, LS, and LS Ultimate trims by 2009 — no P71 variant exists on this model, but the CJB and BJB do reflect some position differences across trim levels, particularly around heated seats, the EATC module, and moonroof-equipped cars. The 150-pin PCM harness — C175T, C175B, and C175E — is shared architecture with the Crown Victoria and Town Car but carries Grand Marquis-specific pin assignments, particularly in C175B where the brake pedal position switch input is present (unlike the Town Car, which uses that pin differently). That split is documented in the connector tables below.
Download Your Schematics:
- 2009 Mercury Grand Marquis Battery Junction Fuse Box Schematic Data Sheet
- 2009 Mercury Grand Marquis Powertrain Control Module Schematic Data Sheet
- 2009 Mercury Grand Marquis Central Junction Box Schematic Data Sheet
Resources:
- Ford OBD-2 Diagnostic Trouble Codes List
- 2003–2011 Panther Platform Resources & Manuals List
- Label Installation Guide
Labels:
In this post:
- Engine Specifications
- Transmission Specifications
- Battery Junction Box Fuse Panel Data & Info
- Powertrain Control Module Data & Info
- Central Junction Fuse Box Data & Info
- Trim Level Fuse Differences
- Known Issues & TSB Reference
- Scheduled Maintenance Intervals
Engine Specifications
The 2009 Grand Marquis runs the same 4.6L 2-valve SOHC "Romeo" V8 that carried the platform from 2003 through 2011. Output is 224 hp at 4,800 rpm and 272 lb-ft at 4,000 rpm on GS and LS trims running single exhaust. The Romeo casting designation refers to the Romeo, Michigan plant — this is not interchangeable with the Windsor-cast 4.6 used in Mustangs and F-150s. By 2009 the ETC system and 4R75E transmission are well-established, and the PCM calibration is stable relative to the 2005 first-year ETC tune. All figures below are SAE net.
| Specification | Value |
|---|---|
| Engine Family | Ford Modular V8 — Romeo cast |
| Displacement | 4.6L (4,601 cc / 280.8 cu in) |
| Configuration | V8, 90° — SOHC, 2 valves per cylinder (16 total) |
| Bore × Stroke | 90.2 mm × 90.0 mm (3.55 in × 3.54 in) |
| Compression Ratio | 9.4:1 |
| Horsepower (GS / LS) | 224 hp @ 4,800 rpm (SAE net) — single exhaust |
| Torque | 272 lb-ft @ 4,000 rpm (SAE net) |
| Redline | ~5,550 rpm |
| Fuel Type | Unleaded — 87 octane minimum (regular) |
| Fuel Injection | Sequential Multi-Port Fuel Injection (SEFI) |
| Throttle Control | Electronic (Drive-By-Wire / ETC) — Gen II, introduced 2005 |
| Ignition | Coil-on-plug (COP) — 8 individual coils, no distributor |
| Engine Oil Capacity | 6 quarts with filter change |
| Engine Oil Spec | SAE 5W-20 (Motorcraft) |
| Coolant Capacity | ~17.9 liters (18.9 qts / 4.7 gal) |
| Coolant Spec | Motorcraft Premium Gold (yellow) — do not mix with green |
| Fuel Tank Capacity | 19 gallons (gasoline) |
Transmission Specifications
The 2009 Grand Marquis uses the 4R75E, the electronically-controlled variant of the 4R75W used in the Crown Victoria. The "E" designation indicates a fully electronic transmission control strategy without a separate transmission control module — the PCM handles all shift logic directly. The 4R75E was phased in on the Grand Marquis when ETC arrived in 2005 and remained through the end of the model run. The turbine shaft speed (TSS) sensor at C175T pin 15 gives the PCM real-time torque converter slip data for TCC control. Fluid spec is Mercon V — do not substitute standard Mercon or Dexron, both will damage the friction material in this unit. Some 2005+ sealed units have no dipstick; fluid level check on those requires a lift and fill-plug procedure.
| Specification | Value |
|---|---|
| Transmission Model | Ford 4R75E 4-speed automatic |
| Type | Rear-wheel drive, 4-speed automatic with overdrive |
| 1st Gear Ratio | 2.84:1 |
| 2nd Gear Ratio | 1.55:1 |
| 3rd Gear Ratio | 1.00:1 |
| 4th Gear Ratio (OD) | 0.70:1 |
| Reverse Ratio | 2.32:1 |
| Turbine Speed Sensor | Yes — TSS (C175T pin 15) feeds PCM for TC slip monitoring |
| Transmission Fluid | Mercon V only — do not use standard Mercon or Dexron |
| Fluid Capacity (pan drop) | ~5 quarts |
| Fluid Capacity (overhaul/dry) | ~12–13 quarts |
| Rear Axle | Ford 8.8 inch — Traction-Lok (limited slip) optional |
| Rear Axle Fluid | 75W-140 synthetic (Traction-Lok) or 80W-90 (standard open diff) |
| Rear Axle Fluid Note | Add 4 oz. Motorcraft XL-3 friction modifier for Traction-Lok |
Battery Junction Box Fuse Panel Data & Info
Location: Engine bay, passenger side, behind battery | All information verified with AllData.
The Battery Junction Box (BJB) is the under-hood high-current distribution center — the first hard protection point between the battery/alternator output and everything downstream. On the 2009 Grand Marquis it carries the heavy-load feeds: starter relay, cooling fan (50A maxi), ABS pump (40A), blower relay, rear defroster relay, PCM power relay, and the two main fuse box feeds (BJB #103 and #104) that energize the cabin CJB circuits. The BJB also hosts the under-hood relays — A/C clutch (201), ignition coil (203), PCM (204), fog lamps (205), fuel (206), horn (209), starter (301), air suspension compressor (302), blower (303), and rear defrost (304) — plus two circuit breakers protecting power seats and power windows. Compared to 2007–2008 Grand Marquis units, the 2009 BJB drops the moonroof circuit at position 2 (now "not used"), moves the cigar lighter to position 108, and the A/C clutch diode at 501 is no longer populated. Relay 202 is also not used on the 2009. If you're sourcing relays, the Grand Marquis BJB uses 1/2 ISO relays at positions 201–209 and Full ISO relays at 301–304 — the same relay format as the Crown Victoria, not the Micro/Mini format used in the Town Car.
Moisture and heat from high resistance are the two failure modes that kill Panthers' BJBs, and they feed each other. Water gets in through a missing or cracked cover, poor cowl drainage, or direct exposure; corrosion forms on fuse legs and bus contacts; resistance builds; heat follows. The symptoms are intermittent no-crank, randomly blown maxi fuses, charging irregularities, or multiple unrelated systems failing at once. The fix that holds is always two steps: eliminate the water path and seal the box properly, then physically inspect every fuse, relay, and bus contact for corrosion or heat discoloration — white and green oxidation on fuse legs, melted plastic at terminals, or arc-burned bus contacts. If you see heat damage, clean won't fix it. Repair or replace the affected terminals. After the repair, do a voltage-drop test across the main BJB feeds and grounds under load — more than 0.1–0.2V across any connection means the resistance is still there and the heat will return.
| # | AMP | FUNCTION |
|---|---|---|
| 1 | 30A | Ignition switch |
| 2 | — | Not used (2007–2008: moonroof) |
| 3 | 10A | Powertrain Control Module (PCM) keep alive power, Canister vent |
| 4 | 20A | Fuel relay feed |
| 5 | 10A | Rear Air Suspension Module (RASM) |
| 6 | 15A | Alternator regulator |
| 7 | 30A | PCM relay feed |
| 8 | 20A | Driver's Door Module (DDM), Door locks (2007–2008) |
| 9 | 15A | Ignition coil relay feed |
| 10 | 20A | Horn relay feed |
| 11 | 15A | A/C clutch relay feed |
| 12 | 20A | Audio (subwoofer) |
| 13 | 20A | Instrument panel power point |
| 14 | 20A | Stop lamp switch |
| 15 | 15A | Fog lamps |
| 16 | 20A | Heated seats |
| 17 | — | Not used |
| 18 | — | Not used |
| 19 | 15A | Powertrain Control Module (PCM), Fuel injectors |
| 20 | 15A | PCM |
| 21 | 15A | Powertrain loads and sensors |
| 22 | — | Not used |
| 23 | — | Not used |
| 24 | 10A | Heated mirror, Rear defrost indicator |
| 101 | 40A | Blower relay feed |
| 102 | 50A | Cooling fan |
| 103 | 50A | Instrument panel (I/P) fuse box feed #1 — I/P fuses 10, 12, 14, 16, and 18 |
| 104 | 50A | Instrument panel (I/P) fuse box feed #2 — I/P fuses 2, 4, 6, 8, 19, 21, 23, and 25 |
| 105 | 30A | Starter relay feed |
| 106 | 40A | Anti-lock Brake System (ABS) module (pump) |
| 107 | 40A | Rear defroster relay feed |
| 108 | 20A | Cigar lighter (2009–2011; 2007–2008: not used) |
| 109 | 20A | ABS module (valves) |
| 110 | 30A | Wiper module |
| 111 | — | Not used |
| 112 | 30A | Air suspension compressor |
| 113 | — | Not used |
| 114 | — | Not used |
| 115 | — | Not used |
| 116 | — | Not used |
| 117 | — | Not used |
| 118 | — | Not used |
| 201 | 1/2 ISO | A/C clutch |
| 202 | — | Not used |
| 203 | 1/2 ISO | Ignition coil |
| 204 | 1/2 ISO | Powertrain Control Module (PCM) |
| 205 | 1/2 ISO | Fog lamps |
| 206 | 1/2 ISO | Fuel |
| 207 | — | Not used |
| 208 | — | Not used |
| 209 | 1/2 ISO | Horn |
| 301 | Full ISO | Starter |
| 302 | Full ISO | Air compressor (air suspension) |
| 303 | Full ISO | Blower |
| 304 | Full ISO | Rear defrost |
| 401 | — | Not used |
| 501 | Diode | Not used (2007–2008: A/C clutch) |
| 502 | Diode | Powertrain Control Module (PCM) |
| 503 | 20A Circuit Breaker | Not used (2007: horn, door latch) |
| 601 | 20A Circuit Breaker | Power seats, Lumbar, Deck lid |
| 602 | 20A Circuit Breaker | Power windows relay feed (RUN/ACC) |
Legend
- # — Terminal Position
- ABS — Anti-lock Brake System
- AMP — Terminal Amperage
- CB — Circuit Breaker
- DDM — Driver's Door Module
- FUNCTION — Circuit Function
- I/P — Instrument Panel
- ISO — International Standards Organization
- LCM — Lighting Control Module
- PCM — Powertrain Control Module (also: Electronic Control Unit)
- PDB — Power Distribution Box
- RASM — Rear Air Suspension Module
Powertrain Control Module (PCM/ECU) Data & Info
Location: Engine bay, driver's side inner fender | All information verified with AllData.
The PCM on the 2009 Grand Marquis is a 150-pin unit using three connectors — C175T (left), C175B (center), and C175E (right) — all black, all keyed differently. The PCM manages fuel delivery, ignition timing, ETC throttle control, transmission shift strategy, emissions, and fuel pump modulation. It also sources the 5V reference voltage to sensors like the MAP, TPS, APP, and fuel tank pressure transducer — if that reference is missing or intermittent at any of those sensors, the PCM logs the fault and the sensor is usually blamed first. Before condemning a sensor on a no-start or drivability complaint, verify that the 5V reference is present at the sensor connector with the key on. If it's missing at multiple sensors simultaneously, the issue is the PCM's reference supply or a short in the reference circuit, not the sensors themselves.
The C175B connector carries the ETC-related signals — Vref 1 (pin 4), Vref 2 (pin 24), and all three APP sensor inputs (pins 5, 17, 28) — along with the HS CAN bus (pins 11 and 23) that ties the PCM into the vehicle network. A failed or corroded C175B is the single most common cause of no-start or ETC wrench-light complaints on these cars when the throttle body and APP sensor check out fine. Pins 47–50 in C175B are the PCM ground cluster — four BK/WH wires all on circuit 570, 18-gauge. Voltage drop across any of those grounds is the first thing to check on any PCM-related complaint before pulling connectors or parts. On the Grand Marquis specifically, C175B pin 8 carries the brake pedal position switch signal on circuit 959 (gray wire) — this differs from the Town Car, where that pin is not used. Pin 21 in C175T carries the anti-theft indicator control on this model, not the engine vacuum signal used on the Crown Victoria.
The C175E connector carries all eight injector controls, all eight COP ignition controls, the O2 sensor inputs, the ETC motor drive wires, and the engine sensor signals — MAF, IAT, CKP, CMP, knock sensors, and cylinder head temperature. If you're chasing a misfire and the plug and COP check out, the next step is inspecting the COP control wires at C175E under load, particularly pins 9–17. Carbon tracking on the COP boot seats or intermittent opens in those circuits can set P030X codes with no visible damage to the coil itself. Full text for any TSB referenced in this post is available through ALLDATA, Mitchell1, or a dealer service department.
C175T (BK) | LEFT (12B637)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | DB/YE | 136 | 20 | Output shaft speed sensor (OSS) signal |
| 4 | — | — | — | Not used |
| 5 | — | — | — | Not used |
| 6 | — | — | — | Not used |
| 7 | — | — | — | Not used |
| 8 | — | — | — | Not used |
| 9 | — | — | — | Not used |
| 10 | — | — | — | Not used |
| 11 | WH/YE | 925 | 20 | Electronic pressure control (EPC) solenoid |
| 12 | — | — | — | Not used |
| 13 | — | — | — | Not used |
| 14 | — | — | — | Not used |
| 15 | DG/WH | 970 | 20 | Turbine shaft speed (TSS) sensor signal |
| 16 | YE/BK | 1144 | 20 | Digital transmission range (DTR) sensor TR1 |
| 17 | LB/BK | 1145 | 20 | Digital transmission range (DTR) sensor TR2 |
| 18 | — | — | — | Not used |
| 19 | — | — | — | Not used |
| 20 | — | — | — | Not used |
| 21 | — | — | — | Not used |
| 22 | — | — | — | Not used |
| 23 | — | — | — | Not used |
| 24 | RD/LG | 392 | 18 | Heated oxygen sensor (HO2S) #12 input |
| 25 | VT/LG | 393 | 18 | Heated oxygen sensor (HO2S) #22 input |
| 26 | — | — | — | Not used |
| 27 | RD/BK | 1268 | 20 | Digital transmission range (DTR) sensor TR3A |
| 28 | WH/BK | 1143 | 20 | Digital transmission range (DTR) sensor TR4 |
| 29 | OG/BK | 923 | 20 | Transmission fluid temperature (TFT) sensor |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | OG/RD | 1269 | 20 | Anti-theft indicator control |
| 33 | — | — | — | Not used |
| 34 | — | — | — | Not used |
| 35 | — | — | — | Not used |
| 36 | — | — | — | Not used |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | OG/YE | 237 | 20 | Shift solenoid A |
| 43 | VT/OG | 315 | 20 | Shift solenoid B |
| 44 | — | — | — | Not used |
| 45 | — | — | — | Not used |
| 46 | VT/YE | 126 | 20 | Torque converter clutch (TCC) solenoid |
| 47 | WH/BK | 389 | 18 | Heated oxygen sensor (HO2S) #12 heater |
| 48 | TN/YE | 390 | 18 | Heated oxygen sensor (HO2S) #22 heater return |
| 49 | — | — | — | Not used |
| 50 | — | — | — | Not used |
C175B (BK) | CENTER (14290)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | GY/BK | 679 | 18 | Vehicle speed signal |
| 2 | GY/RD | 3405 | 20 | Starter relay control |
| 3 | RD/PK | 791 | 20 | Fuel tank pressure transducer sensor signal |
| 4 | WH/LB | 3093 | 20 | Electronic throttle control Vref 1 |
| 5 | TN/YE | 1283 | 20 | Accelerator pedal position (APP) 1 signal |
| 6 | TN/WH | 1284 | 20 | Electronic throttle control signal return |
| 7 | — | — | — | Not used |
| 8 | GY | 959 | 20 | Traction control switch on/off signal |
| 9 | OG | 636 | 18 | Brake pedal position signal |
| 10 | BK | 57 | 18 | Ground |
| 11 | WH/LG | 1827 | 20 | HS CAN+ |
| 12 | LB/OG | 926 | 20 | Modulated fuel pump signal |
| 13 | VT/WH | 91 | 20 | EVAP canister vent control solenoid |
| 14 | OG/LB | 73 | 20 | A/C clutch relay control |
| 15 | PK/LB | 883 | 20 | A/C cycling switch signal |
| 16 | — | — | — | Not used |
| 17 | WH | 3012 | 20 | Accelerator pedal position (APP) 2 signal |
| 18 | — | — | — | Not used |
| 19 | LB/BK | 151 | 20 | Speed control switch reference voltage |
| 20 | YE/BK | 1799 | 20 | RDI / VEMS signal |
| 21 | DG/YE | 238 | 20 | Fuel pump monitor |
| 22 | — | — | — | Not used |
| 23 | PK/LG | 1828 | 20 | HS CAN− |
| 24 | LB/BK | 3091 | 20 | Electronic throttle control Vref 2 |
| 25 | — | — | — | Not used |
| 26 | WH/BK | 1154 | 20 | A/C pressure transducer sensor signal |
| 27 | — | — | — | Not used |
| 28 | WH/RD | 3015 | 20 | Accelerator pedal position (APP) 3 signal |
| 29 | TN/WH | 224 | 20 | Transmission control switch signal |
| 30 | DG/OG | 848 | 20 | Speed control switch signal return |
| 31 | WH/LG | 1215 | 20 | TX signal |
| 32 | YE/LB | 1816 | 20 | Generator communication |
| 33 | — | — | — | Not used |
| 34 | YE/LG | 330 | 20 | Power steering pressure switch signal |
| 35 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 36 | RD | 361 | 20 | Voltage supplied in start and run (overload protected) |
| 37 | — | — | — | Not used |
| 38 | — | — | — | Not used |
| 39 | — | — | — | Not used |
| 40 | BR/WH | 351 | 20 | Reference voltage |
| 41 | GY/RD | 359 | 20 | Signal return |
| 42 | GY/OG | 1216 | 20 | RX signal |
| 43 | — | — | — | Not used |
| 44 | VT | 107 | 20 | Flash / EEPROM power supply |
| 45 | RD/WH | 729 | 20 | Voltage supplied at all times (overload protected) |
| 46 | — | — | — | Not used |
| 47 | BK/WH | 570 | 18 | Ground |
| 48 | BK/WH | 570 | 18 | Ground |
| 49 | BK/WH | 570 | 18 | Ground |
| 50 | BK/WH | 570 | 18 | Ground |
C175E (BK) | RIGHT (12B637)
| PIN | COLOR | CIRCUIT | GAUGE | FUNCTION |
|---|---|---|---|---|
| 1 | — | — | — | Not used |
| 2 | — | — | — | Not used |
| 3 | WH/OG | 369 | 20 | Heated PTC control |
| 4 | — | — | — | Not used |
| 5 | YE | 1817 | 20 | Generator monitor control |
| 6 | LB/BK | 191 | 20 | Vapor management valve control |
| 7 | RD/OG | 229 | 20 | Engine cooling fan motor control |
| 8 | — | — | — | Not used |
| 9 | WH/RD | 1029 | 20 | Coil-on-plug (COP) 8 control |
| 10 | LG/YE | 1021 | 20 | Coil-on-plug (COP) 5 control |
| 11 | PK/WH | 1026 | 20 | Coil-on-plug (COP) 2 control |
| 12 | WH/PK | 1028 | 20 | Coil-on-plug (COP) 3 control |
| 13 | — | — | — | Not used |
| 14 | DG/VT | 1030 | 20 | Coil-on-plug (COP) 4 control |
| 15 | OG/YE | 1025 | 20 | Coil-on-plug (COP) 6 control |
| 16 | PK/LB | 1027 | 20 | Coil-on-plug (COP) 7 control |
| 17 | LG/WH | 1024 | 20 | Coil-on-plug (COP) 1 control |
| 18 | — | — | — | Not used |
| 19 | LB | 1164 | 20 | Injector temperature sensor signal |
| 20 | — | — | — | Not used |
| 21 | BR/LG | 352 | 20 | Differential pressure feedback EGR (DPFE) sensor input |
| 22 | GY | 743 | 20 | Intake air temperature (IAT) sensor signal |
| 23 | — | — | — | Not used |
| 24 | — | — | — | Not used |
| 25 | LB/RD | 967 | 20 | Mass air flow (MAF) sensor signal |
| 26 | TN/LB | 968 | 20 | Mass air flow (MAF) sensor signal return |
| 27 | — | — | — | Not used |
| 28 | GY/LB | 74 | 18 | Heated oxygen sensor (HO2S) #11 input |
| 29 | RD/BK | 94 | 18 | Heated oxygen sensor (HO2S) #21 input |
| 30 | — | — | — | Not used |
| 31 | — | — | — | Not used |
| 32 | RD/PK | 141 | 20 | Injector pressure sensor signal |
| 33 | — | — | — | Not used |
| 34 | DB/YE | 1835 | 20 | Electronic throttle control motor +/− |
| 35 | WH | 556 | 20 | Fuel injector 2 control |
| 36 | BR/LB | 558 | 20 | Fuel injector 4 control |
| 37 | LG/OG | 560 | 20 | Fuel injector 6 control |
| 38 | LB | 562 | 20 | Fuel injector 8 control |
| 39 | — | — | — | Not used |
| 40 | — | — | — | Not used |
| 41 | YE/LG | 1102 | 20 | Cylinder head temperature sensor signal |
| 42 | — | — | — | Not used |
| 43 | — | — | — | Not used |
| 44 | — | — | — | Not used |
| 45 | DB/OG | 282 | 20 | Camshaft position sensor signal |
| 46 | GY/YE | 139 | 20 | Crankshaft position sensor − |
| 47 | BK/PK | 138 | 20 | Crankshaft position sensor + |
| 48 | YE | 1273 | 20 | Knock sensor − |
| 49 | YE/RD | 310 | 20 | Knock sensor + |
| 50 | — | — | — | Not used |
| 51 | OG/YE | 1836 | 20 | Electronic throttle control motor +/− |
| 52 | TN | 555 | 20 | Fuel injector 1 control |
| 53 | BR/YE | 557 | 20 | Fuel injector 3 control |
| 54 | TN/BK | 559 | 20 | Fuel injector 5 control |
| 55 | TN/RD | 561 | 20 | Fuel injector 7 control |
| 56 | — | — | — | Not used |
| 57 | BR/WH | 351 | 20 | Reference voltage |
| 58 | GY/RD | 359 | 20 | Signal return |
| 59 | PK/OG | 1858 | 20 | Electronic throttle control module signal return |
| 60 | YE/WH | 357 | 20 | Throttle position (TPS) sensor signal 2 |
| 61 | GY/WH | 355 | 20 | Throttle position (TPS) sensor signal 1 |
| 62 | LB/RD | 3067 | 20 | Manifold absolute pressure (MAP) sensor input |
| 63 | BR/PK | 360 | 20 | EGR vacuum regulator signal |
| 64 | — | — | — | Not used |
| 65 | — | — | — | Not used |
| 66 | YE/WH | 1857 | 20 | Electronic throttle control module reference voltage |
| 67 | — | — | — | Not used |
| 68 | — | — | — | Not used |
| 69 | RD/WH | 387 | 18 | Heated oxygen sensor (HO2S) #11 heater |
| 70 | YE/LB | 388 | 18 | Heated oxygen sensor (HO2S) #21 heater |
Wire Color Legend
- BK — Black
- BR — Brown
- DB — Dark Blue
- DG — Dark Green
- GY — Gray
- LB — Light Blue
- LG — Light Green
- OG — Orange
- PK — Pink
- RD — Red
- TN — Tan
- VT — Violet
- WH — White
- YE — Yellow
Central Junction Fuse Box Data & Info
Location: Driver's side compartment, under steering wheel | All information verified with AllData.
The Central Junction Box (CJB) is the interior fuse and relay panel — the cabin-side power distribution point that feeds lighting, HVAC, wipers, power windows and locks, the PCM relay coil, ABS, airbag modules, and most of the body electronics. Ford routes power here from two main maxi-fuse feeds out of the BJB (#103 and #104), so if either of those under-hood fuses opens, you'll lose multiple CJB circuits simultaneously. On the 2009 Grand Marquis, position 16 no longer carries the cigar lighter (relocated to BJB #108 starting this year), and position 20 picks up ABS module coverage. The EATC module at position 8 is only present on cars equipped with electronic climate control. If you're chasing an electrical gremlin that kills multiple unrelated circuits, the first question is whether it's a single CJB fuse or one of the upstream BJB maxi-fuses — that narrows down whether the issue is inside or outside the cabin.
The most common real-world CJB failure on Panthers is water intrusion. Cowl drains, windshield seal degradation, and firewall pass-throughs can all put water on or near the CJB. Once moisture gets into the terminals, you get corrosion, then resistance, then heat — and the result looks like random electrical gremlins: intermittent no-start, lights that misbehave, wipers acting on their own, multiple fuse failures with no obvious cause. The correct fix is two steps and both are required: find and eliminate the water source first (drying the carpet without fixing the leak is not a fix), then inspect the CJB connectors and fuse contacts for corrosion or heat-distorted plastic. If the pins are green or black or the connector housing shows any discoloration, cleaning the contacts is a short-term patch at best — repair the terminals and replace anything that's cooked. Corrosion creates resistance, resistance creates heat, and heat left unaddressed will escalate.
| # | AMP | FUNCTION |
|---|---|---|
| 1 | 10A | Ignition (START) — Starter relay coil, Digital Transmission Range (DTR) sensor |
| 2 | 7.5A | Power mirrors, Door lock switches (2007–2008), Mirror switch, Keypad switch, Decklid switch, Adjustable pedal switch, Driver's Door Module, Cluster |
| 3 | 5A | Audio Control Module (ACM) |
| 4 | 10A | Autolamp sensor, Lighting Control Module (LCM) |
| 5 | 7.5A | Lighting Control Module (LCM) |
| 6 | 7.5A | Lighting Control Module (LCM) |
| 7 | 10A | Windshield wiper motor |
| 8 | 10A | Electronic Automatic Temperature Control (EATC) module — equipped vehicles only |
| 9 | 7.5A | Ignition (ON/ACC) — Door lock switch illumination, Heated seat switch illumination, Moonroof (2007–2008), Overhead console, Radio, Antenna, Electrochromatic mirror, Window relay coil |
| 10 | 15A | Multi-function switch — Hazards |
| 11 | 15A | Multi-function switch — Turn signals |
| 12 | 15A | Audio Control Module (ACM) |
| 13 | 10A | Ignition (ON) — Anti-lock Brake System (ABS) module (2007–2008), Rear Air Suspension Module (RASM), Variable Assist Power Steering (VAPS) (2007–2008), Cluster |
| 14 | 15A | Taxi roof lamp switch, Adjustable pedal switch |
| 15 | 10A | Climate control assembly, HVAC module, EATC, Blower motor relay |
| 16 | 20A | On-board diagnostics (OBD II) — 2007–2008 also included cigar lighter |
| 17 | 10A | Temperature blend door actuator, Climate control assembly, Heated seat module driver front, Heated seat module passenger front, Brake shift interlock |
| 18 | 15A | Lighting Control Module (LCM) — Interior lighting |
| 19 | 10A | Lighting Control Module (LCM) — Left-hand low beam |
| 20 | 10A | Digital Transmission Range (DTR) sensor, Ignition (ON/ACC) — Back-up lamps, Anti-lock Brake System (ABS) (2009–2011) |
| 21 | 10A | Lighting Control Module (LCM) — Right-hand low beam |
| 22 | 10A | Passenger Airbag Deactivation (PAD) indicator, Restraints control module (RCM), Occupant Classification System Module (OCSM) |
| 23 | 15A | Multi-function switch (flash-to-pass), Lighting Control Module (LCM) — High beams |
| 24 | 10A | Ignition (ON/ACC) — Passive Anti-Theft System (PATS) module, PCM relay coil, Fuel relay coil, Ignition coil relay coil |
| 25 | 15A | Lighting Control Module (LCM) — Park lamps, corner lamps, license lamps |
| 26 | 10A | Ignition (ON/START) — Cluster, Lighting Control Module, Overdrive cancel switch, Rear defroster relay coil (2006), Traction control switch (2009–2011) |
| 27 | — | Not used |
| 28 | 7.5A | Lighting Control Module (LCM), Brake shift interlock, Anti-lock Brake System (ABS) module |
| 29 | — | Not used |
| 30 | — | Not used |
| 31 | 5A | Lighting Control Module (LCM) — Key in |
| 32 | — | Not used |
| 33 | 10A | Fire Suppression System Module (FSSM), Fire suppression manual switch — if equipped |
| R | RELAY | Accessory Delay Relay |
Legend
- # — Terminal Position
- ABS — Anti-lock Brake System
- ACC — Accessory
- AMP — Terminal Amperage
- DDM — Driver's Door Module
- DLC — Data Link Connector
- DRL — Daytime Running Lamps
- DTR — Digital Transmission Range
- EATC — Electronic Automatic Temperature Control
- FUNCTION — Circuit Function
- I/P — Instrument Panel
- ISO — International Standards Organization
- LCM — Lighting Control Module
- MFS — Multi-Function Switch
- PATS — Passive Anti-Theft System
- PCM — Powertrain Control Module
- R — Relay
- RASM — Rear Air Suspension Module
- VAPS — Variable Assist Power Steering
Trim Level Fuse Differences
The 2009 Grand Marquis was offered in GS, GS Convenience, LS, and LS Ultimate trim levels. The underlying BJB and CJB are the same physical boxes across trims, but several positions are only populated on higher-trim or option-equipped cars — primarily heated seats, moonroof, EATC, and memory-related circuits. If a fuse position on your car doesn't match the table above, check the trim level and option list before assuming a wiring error.
| Position | GS / GS Convenience | LS / LS Ultimate |
|---|---|---|
| CJB #8 | Not populated — manual A/C only | 10A — EATC module (if equipped) |
| CJB #9 | 7.5A — Radio, antenna, overhead console, window relay coil | 7.5A — Adds electrochromatic mirror, heated seat switch illumination |
| CJB #14 | 15A — Adjustable pedal switch only | 15A — Adjustable pedal switch (memory pedals on LS Ultimate) |
| CJB #17 | 10A — Climate control, brake shift interlock | 10A — Adds heated seat modules driver and passenger front |
| BJB #16 | Not populated on GS without heated seats | 20A — Heated seats (LS, LS Ultimate) |
| BJB #24 | Not populated on base trim | 10A — Heated mirror, rear defrost indicator (LS) |
Known Issues & TSB Reference
The items below cover documented issues specific to the 2009 Mercury Grand Marquis — either through Technical Service Bulletins, extended warranty programs, or well-established platform failure patterns that affect this model year. This is not a complete TSB list. TSB numbers and full text are available through ALLDATA, Mitchell1, or a Ford dealer service department.
Lighting Control Module (LCM) — Solder Joint Failure / Intermittent Lighting
Affected: 2003–2011 Grand Marquis (and Crown Victoria). The LCM relay develops a cracked solder joint at the circuit board connection, causing intermittent or total failure of headlamps, taillamps, or other LCM-controlled lighting. Symptoms include lights cutting out randomly with no obvious cause, flickering cluster illumination, or lighting that works only with the connector wiggled. The LCM sits behind the driver's kick panel. If the unit is original, inspect the relay solder joint before condemning the module — a proper re-solder is the correct fix. Replacing the module without addressing the joint just resets the clock on the same failure.Reference: Ford Extended Warranty / TSB — LCM relay solder joint, 2003–2011 Crown Victoria / Grand Marquis
Rear Air Suspension — Compressor Failure / Ride Height Loss
Affected: 2003–2011 Grand Marquis with rear air suspension. The air suspension compressor and bag assembly are known failure points on high-mileage cars. Symptoms include the rear sagging overnight, the compressor running continuously, or a ride-height warning. The compressor relay lives at BJB #302; if the compressor runs but doesn't build pressure, the bags or air lines are the issue, not the electrical system. If the compressor doesn't run at all, start at BJB #112 (30A compressor fuse) and the RASM fuse at BJB #5 before pulling the compressor. Many owners on high-mileage cars convert to passive coilover springs — that's a valid choice, but it disables the RASM and may trigger codes.Reference: Platform pattern failure — rear air suspension, 2003–2011 Panther platform
ETC Throttle Body — Carbon Buildup at Idle
Affected: 2005–2011 Grand Marquis. Drive-by-wire throttle bodies on the Panther platform accumulate carbon deposits on the throttle bore and plate — there's no IAC to compensate the way cable-throttle cars did. The result is rough idle, unstable RPM at operating temperature, and occasionally a wrench light with no hard DTC. Cleaning the throttle bore with an appropriate throttle body cleaner (not carb cleaner — it damages the coating) and re-initializing the ETC with an IDS scan tool or PCM reset procedure typically resolves the issue without parts replacement. If the wrench light returns after cleaning, pull the APP sensor connector at C175B (pins 5, 17, 28) and verify voltage — idle-hunting and rough idle with no DTC often trace back to a dirty throttle bore, not a sensor.Reference: Platform pattern — ETC throttle body carbon buildup, 2005–2011 Panther ETC vehicles
4R75E — TCC Shudder / Premature Lockup
Affected: 2005–2011 Grand Marquis. The 4R75E torque converter clutch (TCC) can apply prematurely in 2nd gear at light throttle, producing a shudder or power drop in the 15–30 mph range. This is a PCM calibration issue — the fix is a PCM reflash with updated tune. If you're feeling an unexplained stumble in that speed range and the transmission is otherwise healthy, this is the first thing to check before assuming a mechanical problem. A worn TCC friction material will produce a similar symptom but typically also shows up as shudder during highway cruising at steady throttle.Reference: Ford TSB — 4R75E TCC application, 2005–2011 Grand Marquis / Crown Victoria / Town Car
Coil-on-Plug (COP) — Misfire with No Visible Coil Damage
Affected: 2005–2011 Grand Marquis. The 2009 uses 8 individual DG-508 coils with no distributor. A common failure pattern is cracked or carbon-tracked COP boots causing a misfire that sets P030X codes with the coil itself testing in spec on the bench. The boots are the weak point — inspect them with a flashlight in a dark garage for any blue arc-tracking to the valve cover. A single bad boot can backfeed voltage spikes into the PCM through the C175E connector if left long enough. Always inspect boots and plug condition together — replacing a coil without checking the plug moves the heat to the next component and doesn't fix the root cause.Reference: Platform pattern — COP boot failure, 2005–2011 Panther platform 4.6L
Scheduled Maintenance Intervals
The intervals below follow Ford's Normal Schedule for cars and minivans as published in the Scheduled Maintenance Guide covering this generation Grand Marquis. Normal schedule applies to typical everyday driving. If the vehicle has seen extended idling, taxi or livery duty, or frequent towing, the Special Operating Conditions schedule applies — most fluid intervals drop significantly under that schedule. A high-mileage Grand Marquis with fleet history should be treated as a heavy-use car regardless of what the odometer says about calendar time.
| Service Item | Normal Interval | Notes |
|---|---|---|
| Engine Oil & Filter | Every 5,000 miles or 6 months | SAE 5W-20 — 6 qts with filter. Taxi or heavy use: every 3,000 mi or 3 months |
| Tire Rotation | Every 5,000 miles | Inspect for wear at each rotation |
| Engine Air Filter | Every 30,000 miles | Motorcraft FA-1783 — replace sooner in dusty conditions |
| Fuel Filter | Every 30,000 miles | Heavy use: every 15,000 miles |
| Spark Plugs | Every 100,000 miles | Motorcraft SP-413 — gapped at 0.054 in. Do not reuse if COP boots are cracked |
| PCV Valve | Every 100,000 miles | Replace at same interval as plugs |
| Serpentine Drive Belt | Inspect at 100,000 miles | Motorcraft JK6-926 — replace if cracked, glazed, or fraying |
| Engine Coolant | First change at 6 years or 100,000 miles | Motorcraft Premium Gold (yellow) — then every 3 years / 50,000 miles after |
| Automatic Transmission Fluid | Inspect at 15,000 mi intervals — change at 150,000 miles | Mercon V only. Taxi / heavy use: every 30,000 miles. Check condition, not just level |
| Brake Fluid | As needed / inspect annually | DOT 3 — replace if fluid is dark or boiling point has degraded |
| Brake System Inspection | Every 15,000 miles | Pads, rotors, lines, hoses, and parking brake. Heavy use: every 5,000 miles |
| Rear Axle Lubricant | Inspect — synthetic fill considered "for life" | Taxi/heavy use: replace every 100,000 miles. 80W-90 standard, 75W-140 synthetic. Add XL-3 friction modifier for Traction-Lok |
| Power Steering Fluid | Check at every oil change | Mercon ATF — ~2 pints capacity. Check condition and level |
| Cooling System Hoses | Inspect at every major service | Replace heater hose assembly at first sign of seeping — Motorcraft KH428 |
Other Mercury Grand Marquis Years
Other Panther Platform Models
Data Disclaimer & Limitation of Liability
Read before using any data published on this site
Informational use only. All fuse assignments, relay positions, wire color codes, pin assignments, circuit numbers, connector identifiers, engine specifications, transmission specifications, torque values, maintenance intervals, and technical service bulletin references published on this site are provided for informational and reference purposes only. This data is not a substitute for a factory Ford, Lincoln, or Mercury service manual, an ALLDATA or Mitchell1 subscription, or the judgment of a qualified, licensed automotive technician.
No warranty. Data provided as-is. Riot Mind Studios, LLC makes no representations or warranties of any kind — express, implied, or statutory — regarding the completeness, accuracy, currency, or fitness for a particular purpose of any data published on this site. All information is provided strictly on an "as-is" and "as-available" basis. We do not warrant that any data point is free from error, omission, or misprint. We do not warrant that this data reflects the current production configuration of any specific vehicle.
Vehicle condition and prior modifications. The Panther Platform vehicles covered by this database (2003–2011 Ford Crown Victoria, Lincoln Town Car, Mercury Grand Marquis, and Mercury Marauder) are aging vehicles with decades of potential service history. Individual vehicles may have been subject to dealer modifications, police upfitter conversions, aftermarket electrical work, wiring repairs, fuse upgrades, or component substitutions that are not reflected in factory documentation or in the data published here. You are responsible for verifying all data against the actual condition of your specific vehicle before performing any repair, diagnostic test, or electrical work.
Model year and trim variation. Fuse assignments, relay types, PCM pin functions, and circuit configurations vary across model years, between trim levels (LX, P71/Police Interceptor, Executive, Signature, GS, LS, HPP, etc.), and in some cases between build dates within the same model year. Data that is accurate for one configuration may be incorrect or inapplicable for another. Always cross-reference this database against a source that is specific to your vehicle's model year, trim level, and build date.
Limitation of liability. To the fullest extent permitted by applicable law, Riot Mind Studios, LLC, its owner, affiliates, and any contributors shall not be liable for any direct, indirect, incidental, special, consequential, or punitive damages arising out of or related to your use of, or inability to use, any data, specification, schematic reference, or other content published on this site. This includes, without limitation: personal injury; vehicle damage; electrical damage; fire; failed emissions or safety inspections; failed diagnostic procedures; incorrect repairs; financial loss; towing costs; or damage to tools or property. Your use of this data is entirely at your own risk.
Professional consultation. Always consult a qualified technician before performing work on safety-critical systems including but not limited to: anti-lock brakes (ABS), supplemental restraint systems (SRS/airbags), fuel delivery, ignition, emissions-related components, and any circuit connected to the Powertrain Control Module (PCM). Incorrect wiring or fuse substitution on these systems can cause personal injury, fire, or permanent damage to vehicle electronics.
Affiliate links. Some links on this site are Amazon affiliate links. Riot Mind Studios, LLC earns a small commission on qualifying purchases at no additional cost to you. Affiliate links do not influence the data or technical content published on this site.
Third-party sources. Some data on this site is derived or cross-referenced from third-party sources including Ford Motor Company factory documentation, ALLDATA, and community-sourced vehicle databases. Riot Mind Studios, LLC does not represent Ford Motor Company, Lincoln, Mercury, or any affiliated brand in any capacity. All trademarks, model names, and manufacturer references are the property of their respective owners and are used here for identification purposes only.
